STEINDORFF
Digital Binocular Microscope
NYMCS-212
User Manual
This manual is written for digital binocular microscope NYMCS-212. To ensure the safety, obtain optimum
performance and to familiarize the use of this microscope, it is recommended strongly that you study this
manual thoroughly before using the microscope and retain this manual in an easily accessible place near
the work desk for future reference.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for STEINDORFF NYMCS-212
Summary of Contents for STEINDORFF NYMCS-212
-
Page 1: User Manual
NYMCS-212 User Manual This manual is written for digital binocular microscope NYMCS-212. To ensure the safety, obtain optimum performance and to familiarize the use of this microscope, it is recommended strongly that you study this manual thoroughly before using the microscope and retain this manual in an easily accessible place near... - Page 2 STEINDORFF 1. Brief introduction Digital binocular microscope NYMCS-212 is widely used in biological, pathological, bacteriological fields for purposes such as observation, research, academic demonstration, clinic, medical inspection. It features more comfortable and reliable operation with modern design and advanced technology.
- Page 3 ® STEINDORFF 2. Main Specifications 1. Mechanical tube: 160mm 2. Objectives (achromatic): Magnification Numerical Focal Length Working distance Aperture f (mm) (mm) 0.10 31.05 37.5 0.25 17.13 7.316 0.65 4.65 0.632 100X 1.25 2.906 0.198 3. Eyepiece Field of view （mm）...
- Page 4 ® STEINDORFF 3. Outfit Name Specifications Standard outfit Stand Body Double-layer mechanical stage Base (LED lamp) Viewing Head Binocular digital head Condenser NA1.2 Abbe Condenser Nosepiece Quadruple Illumination LED lamp Eyepiece 10X Plan Eyepiece Objectives 100X Immersion oil AC Adapter...
- Page 5 ® STEINDORFF 5. Assembly A. Environmental Requirement: 1. Ambient temperature: 5°C to 40°C (41°F to 104°F), Maximum R.H：85%. 2. High Temperature will result in a mildewing, dew and even ruinous instrument. 3. Avoid placing the instrument in a dusty environment. When ending your microscope operation, please cover it with the dust cover.
- Page 6 ® STEINDORFF 5. You should be aware of the cleaning procedures to be used after the use of oil. Wipe oil from the oil immersion objective, and from any other parts in need of cleaning. Clean lenses immediately with xylene after use. Leaving oil on the lens may lead oil to seep behind and harden on the inside of the lens.
- Page 7 ® STEINDORFF Optical part PROBLEM CAUSE SOLUTION The nosepiece is not in the located Turn objective to the right position (objective is not in the center position(the optical light The edge of the of the optical path) center) field of view has...
- Page 8 ® STEINDORFF The condenser is not in the center of the field of view\the condenser Re-install the condenser inclines One side of the image The nosepiece is not in the right Turning it until it reach the is dark “clicked” position...
- Page 9 ® STEINDORFF Electrical Part PROBLEM CAUSE SOLUTION Check the connection of the The lamp can’t light No power supply power cord when turning on the switch The LED lamp is burnt out Replace it Use the specified AC adapter, The lamp burns out...
- Page 10 ® STEINDORFF 4. Double click the shortcut icon on the desktop to preview the images, please insure the camera has linked with the PC, and the driver has been installed rightly, or there will come out an error hint: Cannot preview successfully. Please check your camera.
- Page 11 ® STEINDORFF Besides image windows, many other windows or user interface elements reside within the main window of ScopeImage 9.0. These include menu, toolbars, status bar and control windows, providing additional information about the images or control of the camera.
- Page 12 ® STEINDORFF 5) Basic image operations like other similar software are included in the Image menu. You can adjust the image at ease. 6) Image flip function, include horizontal flip and vertical flip of the active image, and rotate 90 degree, 180 degree, 270 degree or any angle degree of the captured image.
