I/O Information
Front Panel Connectors
I/O Interface
Video
Serial
Ethernet
Parallel
USB (four ports)
PXI trigger
GPIB Controller
ExpressCard/34 module
© National Instruments Corporation
Table 3-1 lists various I/O interfaces and their corresponding NI PXI-8108
external connectors, bus interfaces, and functions.
Table 3-1. NI PXI-8108 I/O Overview
External Connector
DVI-I
(24-pin DSUB)
COM1
(9-pin DSUB)
LAN
(RJ45)
Parallel Port
(36-pin champ)
USB 4-pin Series A stacked
receptacle
Trigger
(SMB)
GPIB
(25-pin Micro D)
ExpressCard/34 slot
Intel Extreme Graphics
controller
16550 RS-232 serial port
10/100/1000 Ethernet
connection
IEEE 1284
Hi-Speed USB
Routing PXI triggers to or
from the backplane trigger bus
General-Purpose Interface
Bus, IEEE 488.1
ExpressCard/34 Expansion
3-1
3
Description
NI PXI-8108 User Manual
