INSTALLATION GUIDE

NI PXI-8109 and NI PXIe-8133

Flex Cable Replacement

Touch the metal part of the case to discharge any static electricity that might be

Caution

on your clothes or body.

This guide describes how to install the flex cable replacement for the

NI PXI-8109 and NI PXIe-8133 embedded controllers. For more detail and

a video demonstration of the cable replacement, please visit

and enter the Info Code

8133FlexReplace

The flex cable can be replaced by hand. No tools are needed and the

controller does not need to be disassembled. Perform the following steps

for installation and removal instructions.

Locate the single-ended board to board flex cable on your

NI PXI-8109 or NI PXIe-8133 embedded controller as shown below in

Figure 1.

1 Board to Board Flex Cable

Figure 1. View of the Controller Back End with Board to Board Flex Cable

ni.com/info
