DVI-I

© National Instruments Corporation
Figure 3-2 shows the location and pinouts for the DVI-I connector on the
NI PXI-8108. Table 3-2 lists and describes the DVI-I connector signals.
Figure 3-2. DVI-I Connector Location and Pinout
Table 3-2. DVI-I Connector Signals
Pin
1
2
3
4
5
6
7
8
9
10
C2
C1
NI PXI-8108
Embedded Controller
Signal Name
TMDS Data2–
TMDS Data2+
TMDS Data2/4 Shield
Reserved
Reserved
DDC Clock [SCL]
DDC Data [SDA]
Analog vertical sync
TMDS Data1–
TMDS Data1+
3-3
Chapter 3 I/O Information
C4
C5
C3
24
8
1 9 17
NI PXI-8108 User Manual
