What You Need to Get Started

SCC-AO10 Isolated Analog Output Module User Guide
Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames, and extensions.
SC-2345 refers to both the SC-2345 connector block and the SC-2345 with
configurable connectors.
SCC refers to any SCC Series signal conditioning module.
To set up and use the SCC-AO10, you need the following items:
❑
Hardware
– SC-2345/2350 with one of the following:
• SCC-PWR01
• SCC-PWR02 and the PS01 power supply
• SCC-PWR03 (requires a 7 to 42 VDC power supply,
not included)
– One or more SCC-AO10
– 68-pin E/M Series DAQ device
– 68-pin cable
– Quick Reference Label
❑
Software
– The latest version of NI-DAQmx
❑
Documentation
– SCC-AO10 Isolated Analog Output Module User Guide
– SC-2345/2350 User Manual
– SCC Quick Start Guide
– Read Me First: Safety and Radio-Frequency Interference
– Documentation for your hardware
– Documentation for your software
❑
Tools
– 1/8 in. flathead screwdriver
– Numbers 1 and 2 Phillips screwdrivers
– Wire insulation stripper
