National Instruments Isolated Analog Output Module SCC-AO10 User Manual

USER GUIDE

SCC-AO10 Isolated Analog
Output Module
Conventions
»
bold
italic
The SCC-AO10 is an isolated voltage output module with an output range
of ±10 V. The output voltage level is controlled by the DAC output of an
E/M Series DAQ device. You can increase the output voltage level to
±20 V by connecting two SCC-AO10 modules in series.
The following conventions are used in this guide:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on
the product, refer to the Read Me First: Safety and Radio-Frequency
Interference document, shipped with the product, for precautions to take.
When symbol is marked on a product it denotes a warning advising you to
take precautions to avoid electrical shock.
When symbol is marked on a product it denotes a component that may be
hot. Touching this component may result in bodily injury.
Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
Italic text denotes variables, emphasis, a cross-reference, an introduction
to a key concept, or text as it appears on a hardware label. Italic text also
denotes text that is a placeholder for a word or value that you must supply.
