INSTALLATION INSTRUCTIONS
NI SCXI -1335
Terminal Block for the NI SCXI-1129
Conventions
»
™
This guide describes how to install and connect signals to the
National Instruments SCXI-1335 terminal block to configure the
NI SCXI-1129 switch module as an 8 × 32 matrix.
Screw terminals on the SCXI-1335 allow you to access the 8 × 32 matrix.
The SCXI-1335 also contains terminals for scanner advanced output and
external input trigger signals, two 128-pin DIN connectors for connecting
columns between modules, and 10-pin headers for connecting rows
between modules using expansion cables.
Refer to the NI Switches Getting Started Guide to determine when to install
the terminal block. Visit
switching solutions.
The following conventions are used in this guide:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on
a product, refer to the Read Me First: Safety and Radio-Frequency
Interference document for information about precautions to take.
