GS-2108C User Manual
Only MultiHost 802.1X is the type of authentication supported in the switch.
In this mode, for the devices connected to this port, once a supplicant is authorized,
the devices connected to this port can access the network resource through this
port.
802.1x Port-based Network Access Control function supported by the switch
is little bit complex, for it just support basic Multihost mode, which can distinguish
the device's MAC address and its VID. The following table is the summary of the
combination of the authentication status and the port status versus the status of port
mode, set in 802.1x Port mode, port control state, set in 802.1x port setting. Here
Entry Authorized means MAC entry is authorized.
Port Mode
Disable Don't Care
Multihost Auto
Multihost Auto
Multihost ForceUnauthorized
Multihost ForceAuthorized
Publication date: April, 2008
Revision A4
Port Control Authentication
Don't Care
Successful
Failure
Don't Care
Don't Care
Table 3-3
120
Port Status
Port Uncontrolled
Port Authorized
Port Unauthorized
Port Unauthorized
Port Authorized
