DIGITAL PIANO
Owner's Manual
C
M
Y
CM
MY
CY
CMY
K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP420K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Medeli DP420K

Summary of Contents for Medeli DP420K

  • Page 1 aw_DP420K_Manual_G03_151028.ai 1 2015/10/28 17:25:16 aw_DP420K_Manual_G03_151028.ai 1 2015/10/28 17:25:16 DIGITAL PIANO Owner’s Manual...
  • Page 2 aw_DP420K_Manual_G03_151028.ai 2 2015/10/28 17:25:22 aw_DP420K_Manual_G03_151028.ai 2 2015/10/28 17:25:22 INFORMATION FOR YOUR SAFETY! THE FCC REGULATION WARNING (for USA) PRECAUTIONS PLEASE READ CAREFULLY BEFORE PROCEEDING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of Please keep this manual in a safe place for future reference.

  • Page 3: Table Of Contents

    aw_DP420K_Manual_G03_151028.ai 3 2015/10/28 17:25:23 aw_DP420K_Manual_G03_151028.ai 3 2015/10/28 17:25:23 Contents Fill In A/B..............17 Panel & Display Description Accompaniment Volume ..........17 Front Panel..............4 Tempo................18 Rear Panel..............4 Pedal................4 DSP Effect Reverb...............19 Setup Chorus...............19 Setup Guide..............6 EQ................19 Connections Connecting a Pair of Headphones.......9 Song Listening to the Songs..........20 Connecting an Audio Equipment .........9 Practise the Songs............20...

  • Page 4: Panel & Display Description

    aw_DP420K_Manual_G03_151028.ai 4 2015/10/28 17:25:23 aw_DP420K_Manual_G03_151028.ai 4 2015/10/28 17:25:23 Panel Description Front Panel 1. [POWER] Switch 5. [RECORD] Button 9. [START/STOP] Button Turn the power on or off. Enter the recording mode. Start or stop playing a song or a style. 2.

  • Page 5: Panel Description

    aw_DP420K_Manual_G03_151028.ai 5 2015/10/28 17:25:23 aw_DP420K_Manual_G03_151028.ai 5 2015/10/28 17:25:23 Panel Description 13. DISPLAY When [SHIFT] is released： When [SHIFT] is pressed： Display all parameters and values 14. [VOICE] Button 22. [BEEP] Key related to the current operation. Enter the voice mode. Turn the beep tone on or off.

  • Page 6: Setup

    aw_DP420K_Manual_G03_151028.ai 6 2015/10/28 17:25:24 aw_DP420K_Manual_G03_151028.ai 6 2015/10/28 17:25:24 Setup This section contains information about setting up your instrument and preparing to play. Please go through this section carefully before turning the power on. Setup Guide Before proceeding to assemble the stand, please get a Philip's screwdriver (not supplied).
  • Page 7 aw_DP420K_Manual_G03_151028.ai 7 2015/10/28 17:25:24 aw_DP420K_Manual_G03_151028.ai 7 2015/10/28 17:25:24 Setup A. Install the legs. First, align the Left and Right legs to each side of the Foot pedal box. Then, insert the screws ⑦ through the holes on the legs and fit them into the Foot pedal box.

  • Page 8: Pedal Jack

    aw_DP420K_Manual_G03_151028.ai 8 2015/10/28 17:25:25 aw_DP420K_Manual_G03_151028.ai 8 2015/10/28 17:25:25 Setup D. Connect the Pedal cable to the Pedal Jack at the rear bottom of the Piano. Then plug the power cable to an AC power outlet. AC power adaptor Now you can turn on the power and enjoy the perfect performance. Pedal cable Pedal jack...

  • Page 9: Connections

    aw_DP420K_Manual_G03_151028.ai 9 2015/10/28 17:25:25 aw_DP420K_Manual_G03_151028.ai 9 2015/10/28 17:25:25 Connections Connecting a Pair of Headphones Plug a pair of standard stereo headphones to the PHONES jack for private practice or late-night playing. Jack 1: When a pair of headphones is plugged into Jack 1, sound can be heard from both headphones and speakers.

  • Page 10: Quick Start

    aw_DP420K_Manual_G03_151028.ai 10 2015/10/28 17:25:25 aw_DP420K_Manual_G03_151028.ai 10 2015/10/28 17:25:25 Quick Start Power Supply Make sure the instrument is powered off. Then turn down the volume. Connect the AC adaptor to the DC IN jack of the instrument. Plug the AC adaptor to an AC outlet. Press and hold the [POWER] button, until the display shows “0.01”, which indicates the instrument is powered on.

  • Page 11: Playing The Voices

    aw_DP420K_Manual_G03_151028.ai 11 2015/10/28 17:25:26 aw_DP420K_Manual_G03_151028.ai 11 2015/10/28 17:25:26 Quick Start Playing the Voices The instrument features a variety of exceptionally realistic voices. Please refer to the Voice List. Press the [VOICE] button to enter the voice mode. The display shows the current voice number, such as “0.01”. Use the [+/YES]/[-/NO] button to select a desired voice.

  • Page 12: Recording

    aw_DP420K_Manual_G03_151028.ai 12 2015/10/28 17:25:26 aw_DP420K_Manual_G03_151028.ai 12 2015/10/28 17:25:26 Quick Start Recording You can record up to 5 user songs on the instrument. Press the [RECORD] button to enter the user song menu. The display shows the current user song number. Use the [+/YES]/ [-/NO] button to select a user song to which the recording will be saved.

  • Page 13: Advanced Use

    aw_DP420K_Manual_G03_151028.ai 13 2015/10/28 17:25:26 aw_DP420K_Manual_G03_151028.ai 13 2015/10/28 17:25:26 Advanced Use Playing the Voices The instrument features a variety of exceptionally realistic voices. Please refer to the Voice List. Playing a voice Press the [VOICE] button or one of the VOICE select buttons to enter the voice mode.

  • Page 14: Playing Voice Demo

    aw_DP420K_Manual_G03_151028.ai 14 2015/10/28 17:25:26 aw_DP420K_Manual_G03_151028.ai 14 2015/10/28 17:25:26 Advanced Use Select the desired upper voice. Press the [LOWER] button to turn on the lower function. The lower indicator lights up. The display shows the current lower voice number, such as“L.23”。 Use the [+/YES]/[-/NO] button or the VOICE select buttons to select the desired lower voice.

  • Page 15: Transpose

    aw_DP420K_Manual_G03_151028.ai 15 2015/10/28 17:25:26 aw_DP420K_Manual_G03_151028.ai 15 2015/10/28 17:25:26 Advanced Use Transpose The transpose function allows the overall pitch of the instrument to be transposed up or down by maximum of one octave in semitone steps. Press and hold [SHIFT], then press the [Transpose+]/[Transpose-] button to enter the setting menu.

  • Page 16: Metronome

    aw_DP420K_Manual_G03_151028.ai 16 2015/10/28 17:25:26 aw_DP420K_Manual_G03_151028.ai 16 2015/10/28 17:25:26 Advanced Use Metronome The Metronome function provides a steady beat to help you practise at a preset tempo. Turn the metronome on/off Press the [METRO] button to turn the metronome on or off. When the metronome is on, the LED indicator of the [START/STOP] button will flash with the current tempo (Red for strong beat and green for weak beat).

  • Page 17: Auto Accompaniment

    aw_DP420K_Manual_G03_151028.ai 17 2015/10/28 17:25:27 aw_DP420K_Manual_G03_151028.ai 17 2015/10/28 17:25:27 Auto Accompaniment The instrument features a variety of piano styles. Please refer to the Style List. Selecting a Style Press the [STYLE] button to enter the style mode. The display shows the current style number, such as “00.1”. Use the [+/YES]/[-/NO] button to select a desired style.

  • Page 18: Tempo

    aw_DP420K_Manual_G03_151028.ai 18 2015/10/28 17:25:27 aw_DP420K_Manual_G03_151028.ai 18 2015/10/28 17:25:27 Auto Accompaniment Tempo Each style, song, metronome, or duet pattern on the instrument is preset with a default tempo. However, you can adjust it with the [TEMPO] button, over the range of 30~280. Press the [TEMPO+]/[TEMPO-] button to adjust the tempo value.

  • Page 19: Dsp Effect

    aw_DP420K_Manual_G03_151028.ai 19 2015/10/28 17:25:27 aw_DP420K_Manual_G03_151028.ai 19 2015/10/28 17:25:27 DSP Effect The DSP simulates sounds in real environment. With the DSP effect, you can add ambiance and depth to your performance in a variety of ways. Reverb Press and hold [SHIFT], then use the keys marked [REVERB +/-] to set the reverb type, over the options: OFF,1~5.

  • Page 20: Song

    aw_DP420K_Manual_G03_151028.ai 20 2015/10/28 17:25:27 aw_DP420K_Manual_G03_151028.ai 20 2015/10/28 17:25:27 Song Listening to the Songs This instrument features some beautiful piano songs. Please refer to the Song List. Play all songs in a loop Press the [SONG] button to enter the song mode. It will play all preset songs in a loop.

  • Page 21: Start Recording

    aw_DP420K_Manual_G03_151028.ai 21 2015/10/28 17:25:28 aw_DP420K_Manual_G03_151028.ai 21 2015/10/28 17:25:28 Song Press again the [RECORD] button to enter the recording standby mode. The [START/STOP] button indicator starts flashing. Now you can set the desired voice, style, tempo etc. The Lower function is automatically disabled.

  • Page 22: Duet

    aw_DP420K_Manual_G03_151028.ai 22 2015/10/28 17:25:28 aw_DP420K_Manual_G03_151028.ai 22 2015/10/28 17:25:28 Duet The duet function will add dynamic elements of a professional-sounding arrangement to your performance. Simply play a chord with your left hand, and the instrument will play a preset duet pattern to produce a beautiful melody. Turn the Duet on/off Press the [DUET] button to turn on the function.

  • Page 23: Twinova

    aw_DP420K_Manual_G03_151028.ai 23 2015/10/28 17:25:28 aw_DP420K_Manual_G03_151028.ai 23 2015/10/28 17:25:28 Twinova The TWINOVA mode splits the keyboard into two independent areas, both have the same pitch and voice, for the convenience of one-to-one teaching. Turn the twinova on/off Press the [TWINOVA] button to turn on the function. The display shows “on”.

  • Page 24: Midi

    aw_DP420K_Manual_G03_151028.ai 24 2015/10/28 17:25:28 aw_DP420K_Manual_G03_151028.ai 24 2015/10/28 17:25:28 MIDI By using the MIDI functions, you can expand your musical possibilities. This section explains what MIDI is, and what it can do. What’s MIDI? MIDI (short for Musical Instrument Digital Interface) allows a wide variety of electronic musical instruments, computers and other related devices to connect and communicate with one another.

  • Page 25: Troubleshooting

    aw_DP420K_Manual_G03_151028.ai 25 2015/10/28 17:25:29 aw_DP420K_Manual_G03_151028.ai 25 2015/10/28 17:25:29 Troubleshooting Problem Possible Cause and Solution The speakers produce a pop sound This is normal and is no cause for alarm. whenever the power is turned ON or OFF. No sound when the keyboard is played. 1.

  • Page 26: Voice List

    aw_DP420K_Manual_G03_151028.ai 26 2015/10/28 17:25:29 aw_DP420K_Manual_G03_151028.ai 26 2015/10/28 17:25:29 Voice List Name Acoustic Grand Piano Acoustic Grand Piano (wide) Bright Acoustic Piano Electric Grand Piano Honky Tonk Piano Harpsichord Electric Piano 1 Electric Piano 2 Clavi Drawbar Organ Percussive Organ Rock Organ Church Organ Reed Organ Accordion...

  • Page 27: Style List

    aw_DP420K_Manual_G03_151028.ai 27 2015/10/28 17:25:29 aw_DP420K_Manual_G03_151028.ai 27 2015/10/28 17:25:29 Style List English Name Romantic 8beat Pop 8Beat Slow Rock Lyric 3Beat Pop Waltz Slow Waltz Waltz1 Waltz2 Waltz3 Vienna Waltz 1-Mar 2-Mar Polka Italian Polka Jazz Pub Jazz 1 Jazz 2 Jazz 3 Jazz 4 Jazz 5...

  • Page 28: Song List

    aw_DP420K_Manual_G03_151028.ai 28 2015/10/28 17:25:29 aw_DP420K_Manual_G03_151028.ai 28 2015/10/28 17:25:29 Song List English Name The entertainer Rialto Ripples (Rag) Neapolitan Song Waltzes Turkish March Schos Doll's Dance No. 2 Minuet In D Major Inquietude Italian Polka Moment Musical Prelude In C-Sharp Major The Happy Farmer The Rag-Time Dance Piano Sonata In C Major, K.330.

  • Page 29: Demo List

    aw_DP420K_Manual_G03_151028.ai 29 2015/10/28 17:25:29 aw_DP420K_Manual_G03_151028.ai 29 2015/10/28 17:25:29 Demo List English Name Fantasia Chpn_op25_no1...

  • Page 30: Midi Implementation Chart

    aw_DP420K_Manual_G03_151028.ai 30 2015/10/28 17:25:29 aw_DP420K_Manual_G03_151028.ai 30 2015/10/28 17:25:29 MIDI Implementation Chart...
  • Page 31 aw_DP420K_Manual_G03_151028.ai 31 2015/10/28 17:25:30 aw_DP420K_Manual_G03_151028.ai 31 2015/10/28 17:25:30...
