Summary of Contents for Medeli DP660
- Page 2 Welcome... Thank you for purchasing our Digital Piano. The use of high technology and the most advanced sampling technique brings you high quality sound and enjoyment. The combination of digital piano and electronic keyboard features let you perform perfectly. We hope this digital piano will be able to explore your creativity, and brings you unlimited happiness and music enjoyment.
-
Page 3: Table Of Contents
Contents Set-up Guide Function 21-24 1.Transpose General Guide 2.Tune The Connectors 3.Octave 1. Using the AC power jack 4.Beat 2.Using headphones 5.Touch 3.Using the AUX.OUT jack 6.Split point 4. Using the foot pedals 7.Key select 5.Using the MIDI IN/OUT jacks 8.Portamento time Basic Operation 9.PAD assign... -
Page 4: Main Features
Main Features 88 graded Hammer key. Multi-functional LCD which can display the staff. Use the +/- key or dial to select voice, style or song. Function features that include transpose, tune, octave, split point, pedal select, touch, DSP, midi etc. 142 high quality voices at all, including 128 GM Voices. -
Page 5: Set-Up Guide
Set-up Guide Open the package, and check whether the following parts are available: 1. Piano body 6. Foot pedal unit 2. Music stand 7. Hand screw (4 pcs.) 3. Right leg component 8. Screws (8 pcs.) 4. Left leg component 9. - Page 6 Follow the illustration below and finish off the set-up procedures. Parts required in this step: 7. Hand screws x 4 8. Screws x 8 9. Screw caps x 8 Caution: When setting up the piano, please use the screws supplied and avoid using the unspecified screws which may damage the piano body and cause the lost of stability.
- Page 7 Use 4 pieces of screws (2 on each side) to stable the center supporting board (5) onto the assembly finished in Part A on the previous page. Put the piano body(1) on the top of the assembly finished in part B, and use 4 pieces of hand screws to stable afterward.
-
Page 8: General Guide
General Guide Top View Rear View Front View Control Panel Headphones Jack Pedal Jack Soft Pedal MIDI IN/OUT Jack Sustenoto Pedal AUX. OUT Jack Sustain Pedal AC Power Jack Music Stand Piano Keyboard... -
Page 9: Front Panel
A.B.C./ POWER FUNCTION- FUNCTION+ STYLES DEMO MELODY OFF /BACK /NEXT RECORD 01 8 Beat 1 07 16 Beat 1 15 Ballad 1 23 SlowRock 1 34 BigBand SEQUENCER ACCOMP / SPLIT / LOW VOICE DUAL 06 8 Beat Pop 08 16 Beat 2 22 Rock'N'R 29 Disco 1 38 Swing 1... -
Page 10: The Connectors
The Connectors Using the AC power jack Ensure the piano is turned off when connecting and disconnecting the power. POWER Turn the volume switch anti-clockwise to reach the minimum volume level. Connect the power cable to the AC power jack on the underside of the piano body. -
Page 11: Using The Foot Pedals
Using the foot pedals Connect the plug of the foot pedal unit to the pedal jack on the rear panel. You will experience the sustain effect. Using the MIDI IN/OUT jacks MIDI stand for Musical Instrument Digital Interface. MIDI is a world wide standard that makes it possible for various electronic musical instruments and other devices. -
Page 12: Voice And Effects
Vocies and Effects Voice selecting Voice numeber 142 voice at all (Appendix 1), including 128 GM voice, 12 Chinese voices, and 2 percussion voices. Voice setting Press [VOICE] button to select three separate voice modes: VOICE R1,VOICE R2,VOICE L. VOICE The default VOICE R1 is No.001;... -
Page 13: Lower Voice
Lower voice You can split the keyboard to right and left area in this function. Press [SPLIT/LOW VOICE] button to turn on the lower voice. LCD lights the lower voice flag and displays "VOICE L" and the lower voice name. Press [+/YES]/[-/NO] button or the dial to select the lower voice number. -
Page 14: Keyboard Function
Keyboard Function The keyboard not only plays three voices at the same time, but also has other necessary functions. ABC on SPLIT POINT(#F3) Turn ABC on. The left area of keyboard is chord area. When you play the chord, both the bass and the chord voice will phonate. -
Page 15: Sustain
Sustain Press the [SUSTAIN] button to turn the SUSTAIN effect on. The sustain icon will appear next to "sustain" on the LCD. All notes played on the SUSTAIN keyboard will have a longer sustain effect. When the Sustain feature is ON, press the [SUSTAIN] button to turn the SUSTAIN effect OFF. -
Page 16: The Accompaniment Section
Sync start flash Press the [SYNC] button. The Beat display will flash at the current tempo when the synchronized start mode SYNC has been selected. The keyboard will start to play the accompaniment by pressing "recognized" chord. Play another chord. START / STOP Press the [START/STOP] button to stop playing the style. - Page 17 Play the Main(A/B) section. Choose the desired style and press the [START/STOP] FILL-IN A button. Press the [FILL A] button.The fill a-a or fill b-a will begin immediately and smoothly lead into the normal. LCD displays :"MAIN A". FILL-IN B Press the [FILL B] button.The fill a-b or fill b-b will begin immediately and smoothly lead into the VARIATION.
-
Page 18: Chord Recognize
Chord Recognize Press the [A.B.C/MELODY OFF] button to turn on the A.B.C. mode. The A.B.C icon will appear next to "A.B.C" A.B.C/ on the LCD. MELODY OFF In this mode, play the chords the chord section below the split point. You can change the chords of the accompaniment by playing keys in the auto accompaniment section of the keyboard using either the "Single Finger"... -
Page 19: Volume Control
Volume Control Accomp volume control To adjust accomp volume control, please [MIXER] button. LCD displays :"100 Accomp V". MIXER You can adjust the volume values of ACCOMP with dial, [+/YES], [-/NO]. Parameter range: 000-127. Press [+] and [-] at the same time will set the ACCOMP volume to 0. -
Page 20: Tempo
Tempo Press the [TEMPO+] or [TEMPO-] button. The tempo value will be flashing. At that time, the tempo can be FUNCTION- FUNCTION+ /BACK /NEXT adjusted in the range of 30-280. Hold down the [TEMPO+] or [TEMPO-] button and adjust the tempo continuously. Press [TEMPO+] and [TEMPO-] simultaneously to set TEMPO TEMPO... -
Page 21: Memory
When the style is playing, press [O.T.S] to turn on the O.T.S mode to inset a "Fill in " automatically. T o insert "FILL A-A'',"FILL A-B'',"FILL B-A'' or "FILL B-B" ,please press memory number. O.T.S. NOTE: Press [O.T.S] key again to turn O.T.S mode off. LCD displays MEMORY. -
Page 22: Album
There are 8 demos at all. You can select the demo number with dial,[+/YES],[-/NO]. DEMO START / STOP Press the [DEMO] or [START/STOP] button to exit from demo mode. NOTE: All function keys on the panel are void. Album Press [ALBUM/SONG/STYLE] button to the album ALBUM / SONG STYLE mode. -
Page 23: Function
Function Press the [FUNCTION+/NEXT] or [FUNCTION-/BACK] button to enter or exit the menu of function. Transpose FUNCTION- FUNCTION+ Press the [FUNCTION+/NEXT] button to adjust /BACK /NEXT transpose parameter with dial,[+/YES],[-/NO]. Parameter Range:-12 to +12 semitones. NOTE: TEMPO TEMPO X'pose 1: Adjust the transpose parameter of voice R1; X'pose 2: Adjust the transpose parameter of voice R2, X'pose L: Adjust the transpose parameter of voice L. -
Page 24: Split Point
Split point FUNCTION- FUNCTION+ Press the [FUNCTION+/NEXT] button to adjust split /BACK /NEXT point parameter with dial,[+/YES],[-/NO] or press the corresponding key. Parameter Range:from 1 to 76. TEMPO TEMPO Key select FUNCTION- FUNCTION+ /BACK /NEXT Press the [FUNCTION+/NEXT] button, you can select portamento or modulation with dial,[+/YES],[-/NO]. -
Page 25: Dsp On/Off
If you select the AccompSt pedal, it has the same function as press the [START/STOP] button by stepping the pedal. If you select the TEMPOTAP pedal, you can quickly adjust the tempo of songs, demos, and styles, by stepping the pedal four times continuously, If you select the MEMORY SELECT pedal, you can select each memory in turn by stepping the pedal. -
Page 26: Local On/Off
Local on/off FUNCTION- FUNCTION+ /BACK /NEXT Press the [FUNCTION+/NEXT] button to turn local on/ off with dial,[+/YES],[-/NO]. TEMPO TEMPO Receive channel Press the [FUNCTION+/NEXT] button to adjust receive FUNCTION- FUNCTION+ /BACK /NEXT channel with dial,[+/YES],[-/NO]. Parameter Range: 1 16 ALL. If you select All , the instrument can receive midi message from all (1-16) midi channel. -
Page 27: Disk
Disk Using floppy disks List Song Names of Disk Insert the floppy disk that containing standard midi file into the disk drive, and then press the [DISK] button, DISK "Wait "will display and the disk icon will flash on the LCD during loading disk song names. -
Page 28: Disk Utility
If the track number of a playing song is more than 64, the LCD will display:"Track Err". If the midi format of a playing song is not format0 or format1 the LCD will display :"Format Err". If the ticks in one beat of a playing song is more than 1024 or less than 24, the LCD displays :"Midi Err". -
Page 29: Disk Format
Disk format Press [UTILITY] button and then press [+] button or UTILITY rotate data dial LCD will display: "U2:Format". FUNCTION- FUNCTION+ /BACK /NEXT Press [FUNCTION+/NEXT] button."FORMAT "will appear on the display. TEMPO TEMPO Press [+] button to execute the format operation (or press [-] button to cancel )."Wait.."will appear and disk icon will flash on the display when format is in process. - Page 30 FUNCTION- FUNCTION+ Press [NEXT] button and LCD will display:"Delete ?" /BACK /NEXT If you are sure, press [+] button and "Wait ."will appear on the LCD. If you do not want to delete the song, press [-] button . TEMPO TEMPO Return to step 2 after the step above.
-
Page 31: Disk Save
NOTE: Load mid function is only used for the midi files that be saved by the piano. If the midi files saved from PC or other midi devices, their names will not display on LCD and this function will be no effect. If you modify the midi file with PC, the midi file will not display in this function. -
Page 32: Record
Input file name: If you want to enter a new name for the saved song, you can press the [ ] keyboard or[ ] keyboard to move the position of character you want to modify and then press the other special keyboard to name the song. -
Page 33: Playback Recording
A melody track will be selected automatically after entering recording mode. You can also press melody track buttons to select other track for recording. ONE TOUCH CONTROL The recording will start as soon as you play a note on the keyboard or press [START/STOP] button. The TEMPO data will display with current TEMPO value START / STOP and beat will appear on the LCD. -
Page 34: Midi
MIDI What is MIDI Musical Instrument Digital Interface. The standard interface between PC and Electronic instrument. It is equipped with standard MIDI interface, including 1 MIDI IN and 1 MIDI OUT. Connection It can connect with PC or other MIDI equipment. MIDI connection Connection rule In midi connection, the equipment which controls... -
Page 35: Specifications
Specifications Keyboard 88 Graded Hammer keys,3 kinds of touch level. Voice 142 Voices Style 100 Styles Demo Song Album 8 Demos and 60 Songs and 100 albums Max, Polyphony 64-note Polyphony (max) Display Multi functional LCD display with blue backlit Switch and Buttons POWER SWITCH, VOLUME,ALBUM/SONG/STYLE,DUAL, O.T.S, DEMO, TOUCH, DIAL, TEMPO,ACCOMP VOLUME,NUMERIC... -
Page 36: Appendix 1-Voice List
Appendix 1-Voice List Santur Jazz Classic... -
Page 38: Appendix 3-Demo List
Appendix 3-Demo List The Fusion The Ballad Latin The Jazz Pop Rock My Motherland Jasmine Appendix 4-Song List Concerto for Violin and Orchestra in a Minor Nocturne Symphone No.94 Suprise... -
Page 39: Appendix 5-Album List
Appendix 5-Album List ALBUM ALBUM ALBUM FUNK&SOUL FAVORITE Dance Of The Crown Beer Tub Boercar 001 Easy Sunday 039 Down By The Riverside 079 The Happiness Of Bumper 002 Moon Light 040 Billy Bailey 080 Amusement 003 Love Me Or Not 041 Greensleeves 004 Someone For Me 042 The Cuckoo... -
Page 40: Appendix 6-Chord Chart
Appendix 6-Chord Chart Chord Name [Abbreviation] Normal Voicing Chord Display Major[M] 1-3-5 Major sixth [6] 1-(3)-5-6 Major seventh [M7] 1-3-(5)-7 Major seventh sharp Eleventh [M7#11] 1-(2)-3-#4-(5)-7 CM7#11 CM7#11 Major add ninth [Madd9] 1-2-3-5 Cmadd9 Cm(9) Major ninth [M9] 1-2-3-(5)-7 CM(9) Major sixth add ninth [6 9] 1-2-3-(5)-6 C6 9... -
Page 41: Appendix 7-Midi Chart
Appendix 7-MIDI Chart Function Transmitted Recognized Remarks Basic Default 1 ch Channel Changed 1 -16 ch 1-16 ch Default Mode Message Altered ** ********* Note 0 —127 36-96 Number : True voice 1-60/72-127 0 —127 Velocity : Note on Note off After key’s Touch Ch’s Pitch Bend...
