Messaging Function

Error Messages on Battery Gauge

Red
4104M-0402-030US
Pattern of
Lamps
4105M-0504-020US
When an error occurs, lamps on battery gauge flash for a set number of times depending on
the cause. See the chart above to determaine the message.
Maintenance
Battery Gauge
Orange
Green
No. of
Flashing
lamps
Lamps stay on
all the time
1 lamp x
flashes once
2 lamps x
flash twice
3 lamps x
flash 3 times
6 lamps x
flash 6 times
7 lamps x
flash 7 times
8 lamps x
flash 8 times
10 lamps x
flash 10 times
Controller inspects the electric circuit of machine
and indicates a message if there is an error.
Under normal condition, lamps stay on steadily.
If there is an error with the control circuit, lamps
flash.
Description
Normal
Faulty battery
connection or
discharged battery
Faulty motor
connection
Short-circuit between
battery and motor
Charger output cable is
connected
Controller in the
protection mode
Control circuit trips
Over voltage
-25-
Corrective Measure
-
→Check battery connection.
If flash continues, charge
battery.
→Check connection of motor.
If flashing continues, please
contact your CANYCOM
representative.
→Please contact your CANYCOM
representative.
→Disconnect Charger output
cable.
→Make sure accelerator lever is
in the stop position and restart
machine. If flashing continues,
please contact your CANYCOM
representative.
→Please contact your CANYCOM
representative.
→Please contact your CANYCOM
representative.
