Charging Battery

• Keep fire and spark away from battery. Hydrogen gas generated from battery is
flamable
• If battery fluid is splashed to clothes or skin, immidiately wash out with plenty
of water. If battery fluid enters into an eye, immidiately wash out with plenty of
water then see a doctor.
• When servicing or replaceing battery, disconnect charger and make sure to turn
main switch to the [OFF] position.
• If the charger works abnormally, turn it off and check connection.
You can chargebattery even battery is installed on machine or uninstalled from
machine.
Charger
Connector
②
①
Shield
4104M-0401-030US
Output Cable
To Outlet
Power Cable
4104M-0401-040US
Operation
Charger
Charging (battery installed)
1. Pull and turn shield to open charger
connector.
2. Connect power cable to charger. Check that
main switch is [OFF], then connect output
cable to charger.
3. Connect power cable to the outlet.
-14-
