MultiModemII User Guide

Using the Modem to Call the Internet

Linux allows different graphic user interfaces (GUI). In the following steps, we'll use
the Gnome Desktop GUI and assume that the Internet Service Provider (ISP) you are
calling assigns you the Domain Name Service (DNS) and Internet Protocol (IP) ad-
dresses. For more information on DNS or IP, see the Linux OS owner's manual or
contact your ISP.
1. On the Task Bar at the bottom of the screen, select the Gnome Footprint.
2. Select Internet from the menu.
3. Select Dialup Configuration Tool.
4. Select Add, and then click Next.
5. Enter the connection name and phone number, and then click Next.
6. Enter your user name and password, and then click Next.
7. Select Normal ISP if your ISP is not listed, and then click Next.
8. Click Finish.

Calling the ISP

1. On the Task Bar at the bottom of the screen, select the Gnome Footprint.
2. Select Internet from the menu.
3. Select RH PPP Dialer.
4. Select the connection name you entered in step 5 of the previous section.
5. Click OK.

Answering Calls

To use the system for answering calls, Linux requires other programs to be installed,
such as Mgetty, Mgetty+Sendfax, and others, depending on your requirements. Each
vendor of Linux has more than adequate information on installing these programs.
F Installing a Modem Under Linux
99
