MultiModemII User Guide
Transmission Level
Frequency Stability
Receiver Sensitivity
AGC Dynamic Range
Interface
Connectors
Cables
Diagnostics
Indicators
Speaker
Manual Controls
Environmental
Storage Temperature
Power Requirement
Power Consumption
Dimensions
Weight
Limited Warranty
-11 dBm (dial-up—varies depending on country setting), -10
dBm (leased-line)
±0.01%
-43 dBm under worst-case conditions
43 dB
TIA/EIA RS-232C/ITU-T V.24/V.28
DB25F RS-232C connector; two RJ-11 phone jacks (BA mod-
el) or three RJ-11 phone jacks (BL model); power connector
One (MT5600BA) or three (MT5600BL) modular telephone
cords (USA); country-specific cordage for International mod-
els; one 9-pin to 25-pin serial cable for International models;
external power transformer
Note: Any cables connected to the computer should be
shielded to reduce interference.
Power-on self test, local analog loop, local digital loop,
remote digital loop
32-character backlit LCD for status and configuration infor-
mation; LEDs for Transmit Data, Receive Data, Carrier
Detect, Off Hook, Terminal Ready, and Test Mode
1-inch speaker for call progress monitoring
Power switch, speaker volume control, four LCD control
buttons
Temperature range 0°–50°C (32°–120°F) ambient under
closed conditions; humidity range 20–90% (non-condensing)
-10° to +85°C (14°–185°F)
120 VAC, 60 Hz, 16 W; 230V/50 Hz optional (international)
12 W @ 0.1 A typical
15.8 cm wide × 22.9 cm long × 3.6 cm high (6.2" × 9.0" × 1.4")
0.9 kg (2 lb.)
10 years
B Technical Specifications
86
