Bellfi res
1.4
OPTIONS AND ACCESSORIES
The following options and accessories can be supplied by your dealer:
Part no
334419
334417
312829
334427
...........
334371
334351 (3x)
Part no
312829
302188
310178
309872
309730
304040
329874
3........
3........
3........
Installation instructions
Option
Convection package View Bell Small 3
• 1x Convection casing
• 1x Convection top plate
• 1x Convection set General
Mantle iron VWBS3
10 cm Frame 4 sided VWBS3 (incl. mantle iron VWBS3)
Black mirror rear wall CBS3 L/R / VWBS3
Fins rear wall CBS3 L/R / VWBS3
Accessorie
Convection set General:
• 1x Flexible aluminium pipe Ø125 mm, L= 3 m (max.)
• 2x Fitting box 135 x 135 mm
• 2x Convection exit grid, white, 145 x 145 mm
• 2x Collar adaptor Ø125 mm
• 4x Hose clamp Ø125 mm
Set carrying brackets (2 pieces)
Bellfi res (M&G) concentric fl ue system
See component summary
Poujoulat (PGI) concentric fl ue system
See component summary
Ontop (Metaloterm US) concentric fl ue system
See component summary
(for convection air extraction)
English
9
