Bellfi res
Model
Gas
Country
Batteries remote control
- Receiver
- Hand-transmitter
Weight:
- Basis model: Hidden Door
- Model: Hidden Door with 10 cm
frame and mantle iron
- Option: Convection package
(*)
: Both burners at maximum. Appliance is on temperature.
(**) : Both burners at maximum. Appliance is cold.
(***) : Both burners at minimum.
Flue gas exhaust and combustion air supply:
Roof-mounted outlet : Concentric fl ue system Ø100 mm - Ø150 mm. Rigid and/or fl exible.
Horizontal wall outlet : Concentric fl ue system Ø130 mm - Ø200 mm. Rigid.
Heat changing surface: Entire front of the appliance.
84
: VIEW BELL SMALL 3 CF (Centre Fire)
: NATURAL GAS
: GB; Great Britain/IE; Ireland
: 4x 1.5V AA
: 1x 9V block
: 84 kg
: 99 kg
: 11 kg
With wall outlet, depending on the fl ue confi guration; Ø100 mm - Ø150 mm or
Ø130 mm - Ø200 mm.
English
: BUTANE / PROPANE
: GB; Great Britain/IE; Ireland
: 4x 1.5V AA
: 1x 9V block
: 84 kg
: 99 kg
: 11 kg
Installation instructions
