Bellfires VIEW BELL SMALL 3 CF/LF Installation Instructions & Manual For Maintenance page 63

Bellfi res
Model
Gas
Country
Product identifi cation no
Type of appliance under CE-norm
Category of appliance
Nominal heat input
(Gross calorifi c value)
Nominal heat output
Effi ciency class
NOx-class
Gas rate (max.)
Supply pressure
Burner pressure (max.) Hot
Burner pressure (max.) Cold
Burner pressure (min.)
Primary air inlet burner Rear
Primary air inlet burner Front
Gas regulator block (remote control)
Main burner
Main burner injector Rear
Main burner injector Front
Pilot light burner
Pilot light burner injector
Gas connection
Concentric fl ue system connection
Installation instructions
: VIEW BELL SMALL 3 LF (Line Fire)
: NATURAL GAS
: GB; Great Britain/IE; Ireland
: 0063CM3684
: C / C / C
11 31 31S
: I natural gas G20
2H
: 11.7 kW
: 9.0 kW
: 1 (85%)
: 5
: 1.10 m 3 /hr.
s
: 20.0 mbar
: 11.2 mbar(*)
: 10.5 mbar(**)
: 0.9 mbar(***)
: 1x Ø12.0 mm
: 1x Ø12.0 mm
: Mertik GV 60
: Line Fire 561x130 mm
: no 190 (= 1x Ø1.90 mm)
: no 230 (= 1x Ø2.30 mm)
: SIT 0.145.019
: no 36 (SIT 0.977.091)
: 3/8" G / Ø12 mm
: Ø100 mm - Ø150 mm or
Ø130 mm - Ø200 mm
English
: BUTANE / PROPANE
: GB; Great Britain/IE; Ireland
: 0063CM3684
: C / C / C
11 31 31S
: I butane/propane G30/G31
3B/P
: Butane (G30) : 11.5 kW
Propane (G31) : 9.5 kW
: 7.3 - 8.8 kW
: 1 (85%)
: 5
: Butane (G30) : 860 gr/hr.
Propane (G31) : 700 gr/hr.
: Butane (G30) : 37.0 mbar
Propane (G31) : 37.0 mbar
: 29.0 mbar(*)
: 29.0 mbar(**)
: 1.0 mbar(***)
: 1x Ø20.0 +corner mm +
2x Ø5.0 mm
: 1x Ø20,0 +corner mm +
2x Ø5.0 mm
: Mertik GV 60
: Line Fire 561x130 mm
: no 110 (= 1x Ø1.10 mm)
: no 130 (= 1x Ø1.30 mm)
: SIT 0.145.019
: no 23 (SIT 0.977.150)
: 3/8" G / Ø12 mm
: Ø100 mm - Ø150 mm or
Ø130 mm - Ø200 mm
85
