Bellfires VIEW BELL SMALL 3 CF/LF Installation Instructions & Manual For Maintenance page 66

Bellfi res
No Article no
31 310908
32 310909
33 310910
34 310912
35 310907
36 302062
37 319842
38 332552
39 332553
40 322552
41 325750
42 325750
43 326055
44 326054
45 334453
46 334369
47 301669
48 301593
49 319664
50 311006
51 301617
88
Description
Pilot light set outer casing, Double fl ame
Packing pilot light set outer casing
Pilot light injector; Natural gas; no 36
Pilot light injector; Butane/Propane; no 23
Piezo electrode for pilot light, 2.8 x 0.5 mm
Nut piezo electrode
Nut thermocouple
Pilot light olive; Ø4 mm, steel
Pilot light nut; Ø4 mm, steel
Pilot light pipe; Ø4 mm, L = 1500 mm, Flexible, Stainless steel
Burner pipe; Ø8 mm, L = 1500 mm, Flexible, Stainless steel - 10 kW+,
"front burner"
Burner pipe; Ø8 mm, L = 1500 mm, Flexible, Stainless steel - 10 kW+,
"rear burner"
Nut; Ø8 mm, compression elbow main burner
Olive; Ø8 mm, compression elbow main burner
Glass View Bell Small 3 front (517 x 747,5 x 4 mm)
Glass View Bell Small 3 side (517 x 328 x 4 mm)
Tube ceramic glue
Black fi bre glass tape 15 x 3 mm, adhesive
Black fi bre glass tape 30 x 2 mm, adhesive
Black fi bre glass tape 20 x 2 mm, adhesive
Black fi bre glass cord Ø10 mm
English
Installation instructions
