RIGID CONCENTRIC FLUE Ø130 mm - Ø200 mm SYSTEM CONNECTION
POSSIBILITIES and with wall outlet Ø100 mm - Ø150 mm
Appliance: Concentric fl ue connection Ø130-Ø200 mm
4
1
Appliance:
View Bell Small 3
Figure 11: Horizontal wall termination
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Installation instructions
100
14
Y
110, 111, 113
128
Distance Y
(min.-max.)
0.5 - 1.0 m
1.0 - 2.0 m
X
19
Assemble restriction plate:
Distance X Concentric connection on
(min.-max.) appliance is Ø130-Ø200 mm
0 - 0.6 m
0 - 2.6 m
English
Wall
Termination
Position
Item descriptions:
see 1.6.2
Width: B = 40 mm
-
