INSTRUCTIONS FOR USE &
MANUAL DAILY MAINTENANCE
DERBY SMALL 3 CF - LF
Gas fi re with closed combustion system
Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re
This document is an essential part of your gas fi re.
Read it carefully before use of the gas fi re and keep it in a safe place!
Serial number:
Production date:

Advertisement

loading

Related Manuals for Bellfires DERBY SMALL 3 LF

Summary of Contents for Bellfires DERBY SMALL 3 LF

  • Page 1 INSTRUCTIONS FOR USE & MANUAL DAILY MAINTENANCE DERBY SMALL 3 CF - LF Gas fi re with closed combustion system Bellfi res wishes you many cosy evenings with your new Bellfi res gas fi re This document is an essential part of your gas fi re. Read it carefully before use of the gas fi...
  • Page 3 Bellfi res English BELLFIRES GAS FIRE WITH CLOSED COMBUSTION SYSTEM: Derby Small 3 CF (Centre Fire) (DYS3 CF) Derby Small 3 LF (Line Fire) (DYS3 LF) Instructions for use...
  • Page 4 Bellfi res English Instructions for use...

  • Page 5: Table Of Contents

    Bellfi res English CONTENTS Page 1. WARRANTY TERMS ................. 2. INSTRUCTIONS FOR USE ............... 3. USING THE APPLIANCE FOR THE FIRST TIME ........4. DAILY MAINTENANCE ................5. ANNUAL MAINTENANCE ................Instructions for use...
  • Page 6 Bellfi res English Instructions for use...

  • Page 7: Warranty Terms

    Bellfi res English WARRANTY TERMS Interfocos Warranty terms Interfocos B.V. guarantees the quality of the supplied Bellfi res hearth and the quality of the materials used. All Bellfi res hearths are developed and manufactured according to the highest possible quality standards. If, despite all this, something should prove amiss with the Bellfi...
  • Page 8 Bellfi res English it has not be used or maintained according to the instructions for use; it has been changed, neglected or roughly treated; it has been damaged as a result of external causes (outside the hearth itself), for example, lightning strike, water damage or fi re; 3.2.

  • Page 9: Instructions For Use

    Bellfi res English INSTRUCTIONS FOR USE INTRODUCTION Congratulations on your purchase of this modern Bellfi res gas fi re. This quality product will provide you with many years of enjoyment due to the fl ame effect and warmth that it provides.
  • Page 10 Bellfi res English Never place fl ammable material on the ceramic log set. The fi lling of the main burner with embers, vermiculite granules, wood logs or pebbles may not under any circumstances be changed or added to. Do not place easily-fl ammable materials, such as nylon clothing or fl...
  • Page 11 Bellfi res English Only front burner ON Derby Small 3 LF The appliance is supplied with a “Line Fire” double burner: Both burners ON Only front burner ON Natural gas: The above sketches provide an impression of the fl ame effect.
  • Page 12 Bellfi res English Butane and Propane: The fl ame effect produced by butane and propane is less realistic than with natural gas. The fl ame effect is less as far as fl ame volume and height are concerned! OPERATION: REMOTE CONTROL 2.4.1 General Read these instructions carefully before lighting the fi...
  • Page 13 Bellfi res English Important Once the fi re is lit, it must burn at maximum for approx. 10 minutes to allow the chimney to come up to temperature! 2.4.2 Hand-held transmitter The remote control works by radio signal. The hand-held transmitter is confi gured in the factory with a unique signal code.
  • Page 14 Bellfi res English Set the display - °C/24 hour or °F/12 hour Clock setting • Connect the batteries. By simultaneously pressing OFF and (small fl ame), can be switched from °F (and 12 hour clock) to °C (and 24 hour clock), or vice versa. •...
  • Page 15 Bellfi res English Figure 3: Receiver “RESET” button Burner: The appliance’s entire burner consists of a “front burner” and a “rear burner”. Burner operation described below applies to: Both “front burner” and “rear burner”. (The AUX-symbol on the hand-held transmitter’s display is visible.) Only “front burner”.
  • Page 16 Bellfi res English You can cycle through the menu with operating possibilities by repeatedly depressing the SET button: and back to the selected starting time (P1 or P2 ) or stopping time (P1 or P2 ) is also shown. Returning to is also possible by pressing the (small fl...
  • Page 17 Bellfi res English Operating night temperature thermostat (The appliance must be in the standby position and the pilot light is burning.) Automatic temperature regulation of the pre-set night temperature. The room temperature is measured and compared with the pre-set night temperature. The fl...
  • Page 18 Bellfi res English Setting the desired temperature • Select the desired mode of operation by pressing the SET button briefl y. • Press the SET button until the temperature indication on the display begins to fl ash. • Set the temperature with (large fl...
  • Page 19 Bellfi res English 2.4.3 Operation (Remote control) Igniting the fi re • Open the gas supply valve in the gas pipe to the fi re. • Switch the hand-held transmitter to the position. • On the hand-held transmitter, press the OFF and (large fl...
  • Page 20 Bellfi res English • Possible error messages: * 3x short audio signal, audible when the motor-knob operates: Receiver batteries need changing soon (having heard this signal, the appliance can be ignited another ten times approximately). * 5 second unbroken tone: Error.
  • Page 21 Bellfi res English • Press button (large fl ame) to increase the fl ame level and to turn on the burner from the stand-by position. (Pressing briefl y the (large fl ame) button gradually increases the fl ames to the high position.) •...
  • Page 22 Bellfi res English Turning the “rear burner” on and off. Figure 5: Rear side of hand-held transmitter (battery cover) Instructions for turning the “rear burner” on and off After igniting the pilot light and burner the “front burner” and “rear burner” are both ON. The AUX-symbol on the hand-held transmitter’s display is visible.
  • Page 23 Bellfi res English Turning on the “rear burner”: • Simultaneously press the SET-button and (large fl ame) to turn the “rear burner” ON. The AUX-symbol on the hand-held transmitter’s display is visible. Notes: The “rear burner” always remains in the last switching position chosen, as long as the appliance is not completely turned off (burner and pilot light OFF).
  • Page 24 Bellfi res English Faults • If the signals from the hand-held transmitter do not seem to be reaching the receiver, the cause may be: * Spent batteries: replace the batteries. * An electronic problem: press the “RESET” button on the receiver. •...

  • Page 25: Using The Appliance For The First Time

    Bellfi res English USING THE APPLIANCE FOR THE FIRST TIME The gas fi re is coated with a lacquer layer resistant to high temperature. During the fi rst hours of operation, the burning in of the lacquer may result in an unpleasant smell.

  • Page 26: Daily Maintenance

    Bellfi res English DAILY MAINTENANCE • Ensure that as little dust, and as few particles of cigarette smoke, candles and oil lamps as possible pollute the air in the room in which the appliance is used. Heating of these particles by the convection system of the appliance could lead to discoloration of the walls and ceiling.

  • Page 27: Annual Maintenance

    Bellfi res English ANNUAL MAINTENANCE It is essential that the appliance, the complete concentric fl ue system (where possible) and the outlet are cleaned and inspected annually by a recognised fi tter/gas specialist. The safe operation of the appliance will thus remain guaranteed.
  • Page 28 Your Bellfi res dealer 01 - 011113 - 335659...
