REMOVING BLADES

1. Turn off the saw and unplug it from the power source.
2. Remove the table insert.
3. Turn the blade tension knob
anticlockwise to remove the
tension from the saw blade.
4. Press down on the top blade
holder and remove the blade.
5. Remove the blade from the lower
blade holder.
6. Lift the blade up and out.

TILTING THE SAW TABLE

1. Undo the table lock knob.
2. Tilt the table to the required angle
then tighten the table lock knob
to secure.
IMPORTANT: For precision work you
should first carry out a trial cut and
then re-adjust the tilt angle as
required.
For precise work always double
check the angle of the saw table
with a protractor or similar angle measure.
