3. Connectors and LEDs

3.1. LEDs
LED
D1
D2
D3
D4
D5
D6
3.2. Jumpers, Headers, and Connectors
Refer to Figure 2 to locate the items described in this section.
J12
J16
J13
Table 2. LED Descriptions
Label
CS_CA Not used
LOS2 Not used
LOS1 ON = no valid clock input
LOL ON = Si5317 is not locked
DUT_PWR ON = Si5317 power is present
3.3V ON = 3.3 V power is present
J14
Figure 2. EVB Jumper Locations
Rev. 0.1
Si5317-EVB
Significance
J15
C8, R8
Si5317
5
