Silicon Laboratories Si5338-EVB User Manual

Si5330/34/35/38 E
Description
The Si5338-EVB is used for evaluating the Si5330/34/
35/38 family of any-frequency, any-output clock
generators and clock buffers.
Rev. 1.4 11/11
B
VALUATION
EVB Features
 Fully powered from a single USB port.
 Onboard 25 MHz XTAL allows standalone
asynchronous operation on the Si5334/35/38.
 GUI programmable V
operate from 3.3, 2.5, or 1.8 V.
 GUI programmable V
four outputs to have its own supply voltage
selectable from 3.3, 2.5, 1.8, or 1.5 V
 GUI-controlled voltage, current, and power
measurements of V
 Voltage supply jumpers allow easy access for use of
external supplies or current measurements.
 Input signal jumpers allow external control of pin
functions such as output enable, phase inc/dec,
frequency inc/dec, and I2C_LSB.
