Ant Unit - Icom IC-A14 Service Manual

[PA UNIT]
REF ORDER
DESCRIPTION
NO. NO.
C717 4030017460 S.CER ECJ0EB1E102K
C764 4030016930 S.CER ECJ0EB1A104K
C765 4030017460 S.CER ECJ0EB1E102K
C766 4030017460 S.CER ECJ0EB1E102K
C770 4030017460 S.CER ECJ0EB1E102K
C790 4030017460 S.CER ECJ0EB1E102K
C791 4030007110 S.CER C1608 CH 1H 680J-T
C792 4030017640 S.CER ECJ0EC1H150J
C793 4030017420 S.CER ECJ0EC1H470J
C794 4030017420 S.CER ECJ0EC1H470J
C795 4030017420 S.CER ECJ0EC1H470J
C796 4030017420 S.CER ECJ0EC1H470J
J1 6910017680 CNR IMSA-9230B-1-04Z140-PT1
J2 6910017680 CNR IMSA-9230B-1-04Z140-PT1
J3 6910017680 CNR IMSA-9230B-1-04Z140-PT1

[ANT UNIT]

REF ORDER
DESCRIPTION
NO. NO.
L1 6200012910 S.COL 0.35-1.6-8TL 45.5N
L45 6200013110 S.COL 0.35-1.6-9TL 52.0N
R338 7030005080 S.RES ERJ2GEJ 823 X (82 k)
C210 4030007050 S.CER C1608 CH 1H 220J-T
C211 4030006980 S.CER C1608 CH 1H 070D-T
C212 4030017350 S.CER ECJ0EC1H020B
[DC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
C125 4030017460 S.CER ECJ0EB1E102K
C126 4030006900 S.CER C1608 JB 1H 103K-T
J1 6910015881 CNR 9230B-1-02Z141-PT1
EP17 6910014640 S.BEA MPZ2012S221A-T
EP18 6910014640 S.BEA MPZ2012S221A-T
H/V
M.
LOCATION
T 20.3/21.9
T 18.8/14
B 11.6/15.5
B 19.4/19.8
B 5.9/14.2
T 5.3/14.5
B 25.2/12.9
T 25.3/15.6
T 17/13.7
T 11.5/14.6
B 12.5/15.5
B 15.6/17.2
H/V
M.
LOCATION
T 3.6/12.1
T 3.5/8.3
T 3.8/14
T 7.5/8.3
T 5.6/7.2
T 5.5/9.7
H/V
M.
LOCATION
T 4.6/6.1
T 7.4/8.2
T 7.1/5.8
T 5.8/8.2
5 - 5
M.=Moun
