SECTION 5
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510026010 BNC-R170
J2 6910015860 IMSA-6277S-O2A-G
SP1 2510001360 K036NAX040A00-55
W1 8900009640 OPC-963
MP1 8010020410 2927 CHASSIS
MP2 8210024590 2927 S-FRONT PANEL (B)
(Incl. MP3, 4, 5, 6, 9, 10, 12)
8210024580 2927 T-FRONT PANEL (B)
(Incl. MP3, 4, 5, 6, 9, 10, 12)
MP3 8210022790 2927 PTT PANEL
MP4 8930069520 2927 PTT BUTTON
MP5 8930074420 3074 PTT RUBBER
MP6 8930073610 SP NET (D)
MP8 8210020550 2721 REAR PANEL
MP9 8310070990 2927 WINDOW PLATE (B)
MP10 8930069510 2927 WINDOW SHEET
MP12 8930074360 2927 4-KEY (D)
8930074370 2927 KEYBOARD (A)
MP13 8930070100 2927 MAIN SEAL (A)
MP14 8930063060 2721 T-RUBBER
MP16 8930069460 2927 SIDE PLATE
MP17 8930069470 2927 TOP PLATE
MP20 8930061880 2721 MIC SPONGE
MP21 8930059360 2600 RELEASE BUTTON
MP22 8930070362 2775 RELEASE PLATE (A)-2
MP23 8610007510 KNOB SPRING NO.7800
MP24 8610012970 KNOB N-350 (Incl. MP23)
MP25 8830003040 3017 ANT NUT
MP26 8810009561 SCREW BT B0 2X6 NI-ZK3 (BT)
MP27 8810009221 SCREW BT B0 2X8 NI-ZK3 (BT)
MP28 8810008641 0Tap 1Flat washer B0 2X4 NI-ZC3 (BT)
MP31 8810010430 SCREW TRUSS M3X5 SUS SSBC
MP32 8310066810 2927 OPTION PLATE
MP33 8930046020 1123 SHEET (A)-1
MP34 8930056540 PUSH SPRING (AH)
MP35 8830001701 VR NUT (Q)-1
MP36 8930048870 2056 A-SPONGE
MP37 8930070010 2893 VOL RUBBER
MP42 8210022780 2927 JACK PANEL
MP43 8810004861 SCREW PH M2X6 ZK3
[MAIN UNIT]
REF ORDER
NO. NO.
J2* 6450000131 HSJ1102-018540
J3* 6510016381 52465-1071
J4* 6510021901 BM02B-ASRS-TF (LF) (SN)
J5* 6450002250 HSJ1456-010320
DS1 5030003070 S11313
MC1 7700002760 EM6027P-46C33-G-01
S23 2260002840 SKHLLFA010
S24* 2230001060 EVQ-PUL 02K
S25* 2260002800 SW-167 (SKQT)
S26* 2260002800 SW-167 (SKQT)
S27* 2260002800 SW-167 (SKQT)
EP20 8930063020 SRCN-2721-SP-N-W
MP3* 8510016130 2721 VCO CASE
MP4 8510016120 2721 VCO COVER
MP5 8930069480 2927 LCD HOLDER
MP6 8210020570 2721 REFLECTOR
MP7 8930070080 WHITE SHEET (V)
MP8 8510017720 2927 MAIN SHIELD
*: Refer to SECTION 7 "BOARD LAYOUTS."
Screw abbreviations

MECHANICAL PARTS

DESCRIPTION
[IC-A14S]
[IC-A14]
[IC-A14S]
[IC-A14]
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[PA UNIT]
REF ORDER
QTY.
NO. NO.
J1* 6910017680 9230B-1-04Z140-PT1
1
J2* 6910017680 9230B-1-04Z140-PT1
1
J3* 6910017680 9230B-1-04Z140-PT1
1
MP1* 8410002531 2681 PA HEATSINK-1
MP2* 8510018750 3074 PA SHIELD PLATE
1
1
[ANT UNIT]
1
REF ORDER
1
NO. NO.
1
1
MP1* 8510017640 2927 ANT PLATE
1
1
1
[DC UNIT]
1
1
REF ORDER
1
1 NO. NO.
1
J1 6910015881 9230B-1-02Z141-PT1
1
1
1
1
[ACCESSORIES]
1
1
REF ORDER
1
NO. NO.
1
1
EP1 3310002130 FA-B02AR
2
EP2 (Optional) BP-232N
2
EP3 (Optional) BC-179
11
EP4 (Optional) BC-174A
1
(Optional) BC-174E
1
EP5 (Optional) BP-261
1
EP6 6910018620 BLACK HANDY STRAP
2
1
MP1 (Optional) MB-94
1
1
1
2
QTY.
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
5 - 1
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[IC-A14] only
[IC-A14]only
[USA] only
[EXP] only
except [USA-01], [EXP-01]
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
