Dsc Unit; Ant Unit; Pwr-Cord Unit - Icom iC-M501EURO Service Manual

[DSC UNIT]

REF ORDER
NO. NO.
IC1 1110003750 S.IC
IC2 1170000280 S.IC
IC3 1130007430 S.IC
Q1 1590000660 S.TRANSISTOR
Q2 1530002850 S.TRANSISTOR
D1 1730002360 S.ZENER
D2 1730002360 S.ZENER
D3 1730002360 S.ZENER
D4 1750000130 S.DIODE
D5 1750000550 S.DIODE
D6 1730002360 S.ZENER
R1 7030003560 S.RESISTOR
R2 7030003600 S.RESISTOR
R3 7030003560 S.RESISTOR
R4 7030003600 S.RESISTOR
R10 7030003530 S.RESISTOR
R11 7030003520 S.RESISTOR
R12 7030003210 S.RESISTOR
R13 7030003680 S.RESISTOR
R14 7030003400 S.RESISTOR
R15 7030003540 S.RESISTOR
R16 7030003800 S.RESISTOR
R17 7030003640 S.RESISTOR
R18 7030003560 S.RESISTOR
R19 7030003670 S.RESISTOR
R20 7030003670 S.RESISTOR
R21 7030003670 S.RESISTOR
R22 7030003410 S.RESISTOR
C1 4030011600 S.CERAMIC
C2 4030006860 S.CERAMIC
C6 4030011600 S.CERAMIC
C7 4030011600 S.CERAMIC
C8 4030011600 S.CERAMIC
C9 4030011600 S.CERAMIC
C10 4510004630 S.ELECTROLYTIC
C11 4030006880 S.CERAMIC
C12 4030011600 S.CERAMIC
C13 4030011330 S.CERAMIC
C14 4030008650 S.CERAMIC
C15 4030007120 S.CERAMIC
J1 6510022240 CONNECTOR
J2 6510022020 S.CONNECTOR
T1 5920000570 TRANSFORMER
EP1 0910052833 PCB
DESCRIPTION
M5218AFP 600C
TLP121 (GB-TPL)
TC7S14FU (TE85R)
DTC144TU T107
2SC4116-BL (TE85R)
MA8062-M (TX)
MA8062-M (TX)
MA8062-M (TX)
DA204U T107
1SS355 TE-17
MA8062-M (TX)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 120 V (12 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 561 V (560 Ω)
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
ECEV1CA100SR
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 391J-T-A
C1608 JB 1H 332K-T-A
C1608 CH 1H 820J-T-A
272MRW-12P
14FLT-SM1-TB
12T01
B 5472C

[PWR-CORD UNIT]

REF ORDER
NO. NO.
FI1 2040001440 S.LC
FI2 2040001440 S.LC
C1 4030006860 S.CERAMIC
C3 4030006900 S.CERAMIC
C5 4030006850 S.CERAMIC
C7 4030007090 S.CERAMIC
C8 4030006860 S.CERAMIC
C9 4030007090 S.CERAMIC
C10 4030007090 S.CERAMIC
J1 6510003130 CONNECTOR
EP1 0910052482 PCB

[ANT UNIT]

REF ORDER
NO. NO.
C5 4030011110 S.CERAMIC
C6 4030011110 S.CERAMIC
EP1 0910052812 PCB
6 - 7
DESCRIPTION
NFM60R20T152
NFM60R20T152
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
SB4P-HVQ-22
B 5486B
DESCRIPTION
GRM42-6 CH 090D 500PT
GRM42-6 CH 090D 500PT
B 5470B
S.=Surface mount
