SIDE TONE FuNCTION
(for A14 only)
When using a third-party headset, the transceiver outputs your
transmitted voice to the headset for monitoring, and a headset
adapter is required
• Connect the optional headset with the transceiver via the
OPC-499 headset adapter
– Illustration shows where the headset adapter jack
insertes into the radio
Jack cover
NOTE: Attach the jack
cover when the optional
equipment is not used.
• SETTING THE SIDE TONE LEVEL
[PTT]
Push [PTT] (see drawing) to
turn the transmit mode ON
During transmit, push [Y ]or
[Z]/[Y]
[ Z] to adjust the level
– ' ST--0' is OFF and 'ST-10' is
the maximum level
– Illustration shows side tone
level indication
FREQuENCIES/CHANNELS NOTES
Side tone level is indicated
©2008 Icom America Inc. The Icom logo is a registered trademark of Icom Inc.40084
QUICK OPERATION GUIDE
ia14
EMERGENCY
Push
(found at the bottom right of the keypad)
func
func
then [0
] (found next to the
121.5
func
func
the PTT to call on the emergency frequency
GENERAL
If the key marking on the keypad is in black, push to
activate. For secondary functions, first push
and then the desired green-marked key
KNOB
(
)
1
Rotate to turn the radio power on or off
and to adjust the audio level
SIDE KEYS
(
)
2
• SET SQUELCH
Push [SQLY] or [SQLZ] (
) to the point where
2
noise is just muted. Push [CLR] to return to frequency mode
key). Use
func
func
1
3
2
