[FUSE UNIT]

REF ORDER
NO. NO.
L901 6200006190 S.COL BLM21PG300SN1D
C901 4030017460 S.CER ECJ0EB1E102K
J901 6910015881 CNR 9230B-1-02Z141-PT1

[ANT UNIT]

REF ORDER
NO. NO.
L801 6200012780 S.COL 0.30-1.4-6TL 27.2N
L802 6200012470 S.COL 0.30-1.7-7TL 45.3N
R801 7030005080 S.RES ERJ2GEJ 823 X (82 k)
C801 4030017460 S.CER ECJ0EB1E102K
C802 4030017380 S.CER ECJ0EC1H050B
C803 4030017410 S.CER ECJ0EC1H240J
C807 4030017620 S.CER ECJ0EC1H100C
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
T
T
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
S.=Surface mount
H/V
LOCATION
10.2/6
6/6.6
H/V
5.7/12.4
6.6/9
3.2/14.1
10/7
6.5/7.1
3.2/10.6
4/11.9
7 - 5
