SECTION 1
P
General
• Frequency coverage
IC-A14
IC-A14S
• Mode
• Channel spacing
• Number of memory channels :
IC-A14
IC-A14S
• Power supply requirement : Specifi ed Icom's battery packs
• Usable temperature range : –10˚C to +60˚C (+14°F to +140°F)
• Current drain (at 7.4 V DC) :
Tx
Rx at stand by
at AF max.
• Antenna connector
• Dimensions
(projections not included)
• Weight
P
Transmitter
• Output power
• Modulation
• Modulation limiting
• Frequency stability
• Audio harmonic distortion : Less than 10% (at 60% mod.)
• Hum and noise ratio
• Spurious emissions
• External MIC connector
P
Receiver
• Receive system
• Intermediate frequencies : 1st 46.35 MHz, 2nd 450 kHz
• Sensitivity
COM band (6 dB S/N)
NAVI band (6 dB S/N)
WX channels (12 dB SINAD)
• Squelch sensitivity
(threshold)
• Selectivity
• Spurious response rejection : AM
• Audio output power
( at 10% distortion with an 8 Ω
load, 30% mod.)
• Hum and noise
• External SP connector
All stated specifi cations are subject to change without notice or obligation.

SPECIFICATIONS

:
TX 118.000 to 136.975 MHz
RX 108.000 to 136.975 MHz
WX (Rx only) 161.650 to 163.275 MHz
TX/RX 118.000 to 136.975 MHz
: 6K00A3E
16K0G3E (IC-A14/Rx only)
: 25 kHz
200 (20 CH × 10 BANKS)
100
7.4 V DC standard
1.5 A
50 mA typical
500 mA
: BNC 50 Ω (nominal)
: 53(W) × 120(H) × 36.9(D) mm
(W) × 4 (H) × 1
2 3 23 9 (D) inch
⁄ ⁄ ⁄
32 32 16
: Approx. 180 g (6.35 oz) (Without the battery pack and antenna.)
: 5.0 W (PEP) typical
1.5 W (CW)
: Low level modulation
: 70 to 100%
: ±5 ppm
: More than 35 dB
: More than 46 dB (except operating frequency ±62.5 kHz range)
: 3-conductor 2.5(d) mm ( 1
⁄
: Double conversion superheterodyne
:
–6 dBµ typical
–3 dBµ typical (IC-A14 only)
–13 dBµ typical (IC-A14 only)
: AM Less than 0 dBµ
FM Less than –5 dBµ
(IC-A14 only)
: 6 dB (More than 7.5 kHz)
60 dB (Less than 25 kHz)
More than 60 dB
FM More than 30 dB
(IC-A14 only)
: More than 700 mW (internal SP)
More than 500 mW (external SP)
: More than 35 dB at 30% mod.
: 3-conductor 3.5 (d) mm ( 1 ⁄8˝)/8 Ω
˝)/150 Ω
10
1 - 1
