INSTALLATION MANUAL
KCIN
Illuminated weatherproof Keypad with Remote Electronics 1, 2 or 3 relays
D. ADDING, CHANGING
OR DELETING A USER CODE
Group 1: From address 00 to address 99,
relay output 1
1. Enter the master code twice
(1 2 3 4 5 default value master code).
2 beeps are emitted to confi rm entry
in programming mode.
2. To add a user code, enter the user
location (from 00 to 99).
If the user location is free 1 beep
is emitted, enter the 4 or 5-digit
User code.
3. To change a user code enter
the user location.
4 beeps are emitted to indicate that
user location is already programmed.
Enter a new 4 or 5-digit code.
A beep is emitted to confi rm the new
user code.
4. To delete a User code enter
the user location.
4 beeps are emitted.
Press 0 0 0 0 0 in 5-digit length code
or 0 0 0 0 in 4-digit length code.
A beep is emitted to confi rm the new
user code.
NOTE: If the Pin code is already programmed
or is identical to the master code,
then 4 beeps are emitted.
Press B to exit from the programming
mode. 2 beeps are emitted to confi rm
that the keypad is in stand-by
operating mode.
E. TIME OUTPUTS
This section allows to program
the illumination time and the Relay
activation time.
1. Enter the master code twice
(1 2 3 4 5 default value master code).
2 beeps are emitted to confi rm
entry in programming mode.
2. Press A0 to program the key-in
keypad time and the keys lit time.
1 beep is emitted. Enter the time in 10th
of second – 10 for 10 seconds up to 99
for 99 seconds the backlighting dims
10 seconds after the last keypress
or switches off after entering a valid
code. Press 00 for permanent
illumination keys.
One beep is emitted to validate the time.
3. Press A1 to program relay 1
output time (door release time).
1 beep is emitted. For a latched output
enter the time in seconds – 01 for 1
second up to 99 for 99 seconds.
Press 00 for a toggled output.
One beep is emitted to validate the time.
4. Press B to exit from
programming mode.
2 beeps are emitted to confi rm that the key-
pad is in stand-by operating mode.
4 beeps indicate a data computing error.
F. RESET MASTER CODE
On stand-by operating mode,
put a jumper on P2.
Wait 1 second and then remove
the jumper. One beep is emitted.
The master code is restored
to its default value 1 2 3 4 5 in 5-digit
code and 1 2 3 4 in 4-digit code.
G. CHANGING THE CODE
BY A USER
To authorize a user to modify its own
User code put a jumper on P3
(to disable the feature remove the jumper).
1. Enter the old user code.
The relay is activated and a beep
is emitted.
2. Enter the 2-digit sub master code
(default sub master code A and B).
A beep is emitted to authorise
the modifi cation.
3. Enter the new user code.
2 beeps are emitted to confi rm
the new code.
4. Check the new user code to be sure
of the modifi cation.
H. SETTING A SUB MASTER CODE
The Sub Master code allows the user
to change its own code without entering
in programming mode. For security
reasons the code need to be changed
periodically. This feature makes it easier
and faster to change its code.
