Specifications; Installation Instructions - Altronix ALTV2432ULCB Installation Manual

These Altronix CCTV Power Supplies provide 24VAC/28VAC, (ALTV2432UL and ALTV2432ULCB provide 24VAC),
distributed via thirty-two (32) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video
accessories.
Thirty-two (32) Output ALTV2432UL Reference Chart:
Altronix
Model Number
ALTV2432UL
ALTV2432ULCB
ALTV2432300UL
ALTV2432300ULCB
ALTV2432600UL
ALTV2432600ULCB
• UL Listed for Commercial CCTV Equipment (UL2044).
CUL Listed - CSA Standard C22.2 No.1-98, Audio,
Video and Similar Equipment.
• Surge suppression.
• AC power LED indicator.
• Power ON/OFF switch / circuit-breaker.
1. Mount unit in desired location.
2. Turn OFF main switch on unit. (Figs. 1-3, pgs. 4-6).
3. All units are factory set for 24VAC operation.
For 28VAC operation (where available) adjust unit prior to mounting and applying power as follows: Change the wire
position so that the black wire [28V] is connected to the terminal marked [P] and the yellow wire [24V] is connected
to the terminal marked [S].
4. Connect AC power to the black and white flying leads of the transformer(s) (Figs. 1-3, pgs. 4-6), secure green lead to
earth ground. Use 18 AWG or larger for all power connections.
Keep power limited (PTC protected outputs only) wiring separate from non-power limited wiring.
Minimum .25" spacing must be provided. Use separate knockouts.
5. Measure output voltage before connecting devices. This helps avoid potential damage.
CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting
the output voltage.
6. Connect devices to terminals marked [1P - 1N through 16P - 16N] on PD16W/PD16WCB board
(Figs. 1-3, pgs. 4-6), carefully observing polarity. Terminals marked [1P - 16P] are of the same polarity.
24VAC 7 amp
24VAC 7 amp
24VAC 12.5 amp
28VAC 10 amp
24VAC 12.5 amp
28VAC 10 amp
24VAC 25 amp
28VAC 20 amp
24VAC 25 amp
28VAC 20 amp

Specifications:

Installation Instructions:

Overview:
32 - x
32 x -
32 - x
32 x -
32 - x
32 x -
• Unit maintains camera synchronization.
• Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions:
13"H x 13.5"W x 3.5"D
- 2 -
3.5 amp 3.5 amp 250V
2.5 amp 3.5 amp 250V
3.5 amp -
2.5 amp -
3.5 amp -
2.5 amp -
2.9 amp
2.9 amp
2.7 amp
2.7 amp
5.4 amp
5.4 amp
