ALTV2432 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV2432
- 24VAC @ 8 amp (200VA)
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432350
- 24VAC @ 14 amp (350VA)
or 28VAC @ 12.5 amp (350VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432600
- 24VAC @ 28 amp (700VA)
or 28VAC @ 25 amp (700VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432CB
- 24VAC @ 8 amp (200VA)
- Thirty-two (32) PTC Protected Outputs.
• ALTV2432350CB
- 24VAC @ 14 amp (350VA)
or 28VAC @ 12.5 amp (350VA).
- Thirty-two (32) PTC Protected Outputs.
• ALTV2432600CB
- 24VAC @ 28 amp (700VA)
or 28VAC @ 25 amp (700VA).
- Thirty-two (32) PTC Protected Outputs.
Rev. 021704
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV2432 Series
Summary of Contents for Altronix ALTV2432 Series
-
Page 1: Installation Guide
ALTV2432 Series CCTV Power Supplies Installation Guide Models Include: • ALTV2432 • ALTV2432CB - 24VAC @ 8 amp (200VA) - 24VAC @ 8 amp (200VA) - Thirty-two (32) Fuse Protected Outputs. - Thirty-two (32) PTC Protected Outputs. • ALTV2432350 • ALTV2432350CB... -
Page 2: Specifications
Overview: These Altronix CCTV Power Supplies provide 24VAC/28VAC distributed via thirty-two (32) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Thirty-two (32) Output ALTV2432 Reference Chart: Altronix Model Number 24VAC 8 amp 3.5 amp 2.9 amp... -
Page 3: Terminal Identification
9. Upon completion of wiring, secure enclosure door with screws (supplied). Caution: Equipment to be installed / serviced by authorized / trained personnel only. Shut branch circuit power before installing / servicing equipment. WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This installation should be made by qualified service personnel and should conform to all local codes and in accordance with the National Electrical Code. - Page 4 Fig. 1 ALTV2432 • ALTV2432CB Used on PTC Models (example: ALTV2432CB) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 common 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16...
- Page 5 Fig. 2 ALTV2432350 • ALTV2432350CB Used on PTC Models (example: ALTV2432350CB) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 common 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16...
- Page 6 Fig. 3 ALTV2432600 • ALTV2432600CB Used on PTC Models (example: ALTV2432600CB) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 common common 1 2 3 4 5 6 7 8...
- Page 7 Enclosure Dimensions: 13"H x 13.5"W x 3.5"D 3.25" TOP ONLY 1.1875" 12.5" 3.25" 1.1875" .75" 1.5" 6.25" 11" 11.75" 1.1875" 3.25" .81" 1.4" 1.4" 5.5" 6.5" 11.66" 12.1" 13" - 7 -...
- Page 8 Notes: Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. IIALTV2432Series C10D MEMBER - 8 -...
