Altronix ALTV2432ULCB Installation Manual page 6

Fig. 3
ALTV2432600UL • ALTV2432600ULCB
1 2 3 4 5 6 7 8
Connected
to Door
Ground
115VAC input
50/60 Hz.
Black
Lead
White
Lead
common
9 10 11 12 13 14 15 16
outputs
N
protected
P
outputs
For continuous protection against risk of fire
replace fuses with same type and rating.
3.5A 250V
non-power limited
XFMR*
non-power limited
common
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
outputs
N
protected
P
outputs
For continuous protection against risk of fire
replace fuses with same type and rating.
3.5A 250V
Power
Switch
non-power limited
XFMR*
- 6 -
Used on PTC Models
(example: ALTV2432600ULCB)
Power Limited Class 2
1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16
N
outputs
protected
P
outputs
Power Supply Board
PTC's
