ALTV2432220 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV2432220
- 24VAC @ 8A (200VA)
or 28VAC @ 7A (200VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432350220
- 24VAC @ 14A (350VA)
or 28VAC @ 12.5A (350VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432600220
- 24VAC @ 28A (700VA)
or 28VAC @ 25A (700VA).
- Thirty-two (32) Fuse Protected Outputs.
• ALTV2432CB220
- 24VAC @ 8A (200VA)
or 28VAC @ 7A (200VA).
- Thirty-two (32) PTC Protected Outputs.
• ALTV2432350CB220
- 24VAC @ 14A (350VA)
or 28VAC @ 12.5A (350VA).
- Thirty-two (32) PTC Protected Outputs.
• ALTV2432600CB220
- 24VAC @ 28A (700VA)
or 28VAC @ 25A (700VA).
- Thirty-two (32) PTC Protected Outputs.
Rev. 122007
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV2432220 Series
Summary of Contents for Altronix ALTV2432220 Series
- Page 1 ALTV2432220 Series CCTV Power Supplies Installation Guide Models Include: • ALTV2432220 • ALTV2432CB220 - 24VAC @ 8A (200VA) - 24VAC @ 8A (200VA) or 28VAC @ 7A (200VA). or 28VAC @ 7A (200VA). - Thirty-two (32) Fuse Protected Outputs. - Thirty-two (32) PTC Protected Outputs.
-
Page 2: Specifications
Overview: ALTV2432220 Series CCTV Power Supplies provide 24VAC/28VAC distributed via thirty-two (32) fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. Thirty-Two (32) Output ALTV2432220 Reference Chart: Total Output Number Fuse Output Current 220VAC Altronix... -
Page 3: Terminal Identification
(servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ALTV2432220 Series - 3 -... - Page 4 XFMR 28VAC Output 220VAC Input, 250V 50/60 Hz Lead Black Lead Terminal Blocks for Fig. 1 Hookup Hookup Brown Brown Black Yellow 24VAC or 28VAC fused or PTC protected outputs Black Yellow 1 through 16. - 4 - ALTV2432220 Series...
- Page 5 28VAC Output 250V 220VAC Input, 50/60 Hz Red Lead XFMR* Black Lead Terminal Blocks for Fig. 2 Hookup Hookup Brown Brown Black Yellow 24VAC or 28VAC fused or PTC protected outputs Black Yellow 1 through 16. ALTV2432220 Series - 5 -...
- Page 6 (Factory Set) 28VAC Output XFMR* XFMR* 250V 220VAC Input, 50/60 Hz Terminal Blocks for Fig. 3 Hookup Hookup Brown Brown Black Yellow 24VAC or 28VAC fused or PTC protected outputs Black Yellow 1 through 16. - 6 - ALTV2432220 Series...
-
Page 7: Enclosure Dimensions
(279mm) 0.9375” 1.40” (24mm) 1.40” (36mm) (36mm) 5.10” 5.10” (130mm) (130mm) 13.0” (330mm) 5.10” (130mm) 6.5625” (167mm) 0.9375” (24mm) 3.25” 3.25” (83mm) (83mm) 3.25” (83mm) 1.0” 1.0” (25mm) (25mm) 1.0” 10.5” 1.0” (25mm) (267mm) (25mm) ALTV2432220 Series - 7 -... - Page 8 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. MEMBER IIALTV2432220Series A12P - 8 - ALTV2432220 Series...
