Altronix ALTV2432ULCB Installation Manual page 5

Fig. 2
ALTV2432300UL • ALTV2432300ULCB
1 2 3 4 5 6 7 8
Connected
to Door
Ground
Black Lead
common
9 10 11 12 13 14 15 16
outputs
N
protected
P
outputs
For continuous protection against risk of fire
replace fuses with same type and rating.
3.5A 250V
Power
Switch
non-power limited
115VAC input
50/60 Hz
White Lead
1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16
N
outputs
protected
P
outputs
For continuous protection against risk of fire
replace fuses with same type and rating.
3.5A 250V
non-power limited
XFMR*
- 5 -
Used on PTC Models
(example: ALTV2432300ULCB)
Power Limited Class 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
common
N
outputs
protected
outputs
Power Supply Board
P
PTC's
