ALTV2432UL3 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV2432300UL3
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Thirty-two (32) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
• ALTV2432600UL3
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Thirty-two (32) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
• ALTV2432300ULCB3
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Thirty-two (32) PTC Protected Outputs.
- Factory installed 3-wire line cord.
• ALTV2432600ULCB3
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Thirty-two (32) PTC Protected Outputs.
- Factory installed 3-wire line cord.
Rev. 020604
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV2432UL3 Series
Summary of Contents for Altronix ALTV2432UL3 Series
- Page 1 ALTV2432UL3 Series CCTV Power Supplies Installation Guide Models Include: • ALTV2432300UL3 • ALTV2432300ULCB3 - 24VAC @ 12.5A (300VA) - 24VAC @ 12.5A (300VA) or 28VAC @ 10A (280VA). or 28VAC @ 10A (280VA). - Thirty-two (32) Fuse Protected Outputs. - Thirty-two (32) PTC Protected Outputs.
-
Page 2: Specifications
Overview: ALTV2432UL3 Series CCTV Power Supplies provide 24VAC/28VAC distributed via thirty-two (32) fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. Thirty-two (32) Output ALTV2432UL3 Reference Chart: Altronix Model Number 24VAC 12.5A 3.5A 2.7A ALTV2432300UL3... -
Page 3: Terminal Identification
5. Set power disconnect circuit breaker to RESET (ON) position (Figs. 1-2, pgs. 4-5). 6. Measure output voltage before connecting devices. This helps avoiding potential damage. CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting the output voltage. 7. - Page 4 Fig. 1 ALTV2432300UL3 • ALTV2432300ULCB3 Used on PTC Models (example: ALTV2432300ULCB3) Power Limited Class 2 common 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 common 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16...
- Page 5 Fig. 2 ALTV2432600UL3 • ALTV2432600ULCB3 Used on PTC Models (example: ALTV2432600ULCB3) Power Limited Class 2 common common 1 2 3 4 5 6 7 8 common 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16...
-
Page 6: Enclosure Dimensions
Enclosure Dimensions 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.55mm) 1.40” 4.85” 4.85” 1.40” (36mm) (123mm) (123mm) (36mm) 1.20” (31mm) 3.25” (83mm) 12.5” (318mm) 1.20” 1.20” 0.75” 0.75” (31mm) 11.0” (31mm) (19mm) (19mm) (279mm) 0.9375” 1.40” 1.40” (24mm) (36mm) (36mm) 5.10”... - Page 7 Notes: ALTV2432UL3series - 7 -...
- Page 8 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. MEMBER IIALTV2432UL3 Series D05P - 8 - ALTV2432UL3series...
