2.3.3.3 Connecting the Networked Door Strike Intermediate Relay
For wiring an electronic door strike to work over a network, we recommend the use of our external
Networked Door Strike Intermediate Relay (CD# 011270).
This product provides an easier method of connecting standard door strikes as well as AC and
higher voltage devices. See
802.3af Compliant Ethernet Switch
CyberData
Device
Operations Guide
Figure 2-5
Figure 2-5. Wiring Diagram
See Section 2.4.12, "Configure the Door Strike
Relay" for configuration options.
930796L
for the wiring diagram.
Installing the VoIP Outdoor Intercom
Intercom Setup
+
AC Source
DC Source OR
Sense Input Aux Button
