IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fi replace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
070211-16
TC54
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART# TC54.NG04C2
For TC54 Series C
TC54.NG04C2
5056.4256204

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC54.NG04C2 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC54.NG04C2

Summary of Contents for Town & Country Fireplaces TC54.NG04C2

  • Page 1 Operating Instructions supplied with the fi replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC54 TRANQUILITY BURNER KIT INSTRUCTIONS PART# TC54.NG04C2 For TC54 Series C 070211-16 TC54.NG04C2 5056.4256204...

  • Page 2: Contents Of Package

    Contents of Package BURNER ASSEMBLY PEBBLE ASSEMBLY 7lbs SAND LINE COVER, LEFT LINE COVER, RIGHT PKG. TAPERED PLUGS (not shown) TC54.NGO4C2 070211-16...

  • Page 3: Front Connections

    Tranquility Burner Installation Fig #1 A panel set must be used in conjunction with the installation of the burner assembly. See Installation and Operating Instructions manual for details. Typically all panels except the right side should be installed prior to burner installation.
  • Page 4 Fig. #5 RED END 6. Remove access cover from side of fi rebox. Remove access cover from side of fi rebox. Secure the bulkhead plate and gasket to the fi rebox. (2 screws) Attach the ignition and sensor wires to the module on the front valve. Red end to the connector marked by the red dot, white end to the connector marked by the white dot(Fig.

  • Page 5: Sand Placement

    11. Place tapered plugs into all burner ports Fig #8 to prevent sand from entering the burn- ers. (Fig. #8) PLUGGING PORTS WITH TAPER PLUGS CAUTION: Before pouring sand ensure all connections and adjustments are made. Removing sand is very difficult. Fig #9 12.
  • Page 6 14. Remove tapered plugs. The pebble Fig #11 assemblies may now be installed. Lift the assembly carefully by the bottom and place on tray aligning with locator pins. The hollowed rock on the assembly covers the pilot. (Fig. #11) INSTALL PEBBLE ASSEMBLY Fig #12 15.

  • Page 7: Propane Conversion

    Propane Conversion Kit# TC54.LPCE02 for use with model / MINIMUM RATE SCREW (5005.015) WARNING Pour utilise avec du modèle: TC54.CE2 Date: ______________________ This conversion kit shall be installed by a By / Par: ___________________ This appliance was con- LP GAS/ qualifi ed service agency verted to PROPANE GAS DU GAZ LP...
  • Page 8 Fig #17 6. With a 7/16” wrench loosen the pilot head on the pilot assembly. (Fig. #17) Hold the base of the pilot assembly secure with a wrench. Fig #18 Slide the pilot adjustment band over and ensure that the hole in the orifi ce band is showing.
  • Page 9 8. Remove access panel, 10 screws, and Fig #20 set aside. (Fig. #24) The minimum rate screw is sealed with an o-ring. Use a thin bladed screwdriver 9. Remove the minimum rate screw located to back the screw out to the limit of the in the valve.

  • Page 10: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from Fig #27 the supply pressure test port or manifold pressure test port. Verify gas pressures with the fi replace lit and on the highest setting. SUPPLY PRESSURE MANIFOLD...

  • Page 11: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air to the gas burner. The shutter should be set to fully closed for natural gas or fully open for propane. See Fig. #28 for proper plame pattern. Fig #28 The fl ame should be just orange and “lazy”...
  • Page 12 TC54 Tranquility Burner Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM .... DESCRIPTION ..............PART NO. #1....TC54 TRANQUILITY BURNER KIT ........TC54.NG04.C #2....BURNER ................TCRP.50118399 #3....PILOT ASSEMBLY, CONVERTIBLE (2 Required) ....TCCV.5005025B #4....ORIFICE, NG (#29) (2 Required) ......... 5022.135 #5....
  • Page 13 Notes TC54.NGO4C2 070211-16...
  • Page 14 Notes TC54.NGO4C2 070211-16...
  • Page 15 Notes TC54.NGO4C2 070211-16...
  • Page 16 Technical support: 1-250-748-1184 Web site: www.townandcountryfi replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
