- Page 1 User Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ......................3 What is Included ..........................3 Unpacking Instructions ........................3 Claims ............................... 3 Text Conventions ..........................3 Symbols ............................3 Disclaimer ............................3 Product at a Glance .......................... 4 Safety Notes ............................. 4 2. -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery. Text Convention Meaning 1—512... -
Page 4: Product At A Glance
Product at a Use on Dimmer Auto Programs Outdoor Use Auto-ranging Power Supply Glance Sound-Activated Replaceable Fuse User-Serviceable Master/Slave Safety Notes These notes include important information about the mounting, usage, and maintenance of this product; read before using the product. ·... -
Page 5: Introduction
2. I NTRODUCTION Overview Microphone Display DMX In DMX Out Menu Buttons Size M12 Threaded Hole Wedge™ Tri User Manual Rev. 3 Page 5 of 20... -
Page 6: Overview (Cont.)
Overview (cont.) IRC-6 Sensor LEDs Size M12 Size M10 Threaded Hole Threaded Hole Fuse Holder Power In Power Out Page 6 of 20 Wedge™ Tri User Manual Rev. 3... -
Page 7: Dimensions
Dimensions 4.1 in 104 mm 4.3 in 108 mm 4.3 in 108 mm 4.3 in 108 mm Wedge™ Tri User Manual Rev. 3 Page 7 of 20... -
Page 8: Setup
3. S ETUP AC Power The Wedge™ Tri has an auto-ranging power supply and it can work with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 9: Power Linking
The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region. -
Page 10: Mounting
Secure the safety cable using the M10 Threaded passageway on the back of the product Mounting Hole Mounting Clamp (such as CLP-15 or CLP-15N clamp from CHAUVET® works Mounting Clamp with M12 hole) (such as the CLP-10 or CLP-35HC clamp from CHAUVET® works with... -
Page 11: Operation
4. O PERATION Control Panel To access the control panel functions, use the four buttons located underneath the display. Operation Button Function <MENU> Selects an operation mode <UP> Scrolls up the list of options or selects a higher value <DOWN> Scrolls down the list of options or selects a lower value <ENTER>... -
Page 12: Configuration (Dmx)
Configuration Set the product in DMX mode to control with a DMX controller. Connect the product to a suitable power outlet. (DMX) Connect a DMX cable from the DMX output of the DMX controller to the DMX input socket on the product. DMX Personality When selecting a starting DMX address, always consider the number of DMX channels the selected DMX mode uses. -
Page 13: Dmx Channel Modes, Assignments, And Values
DMX Channel Modes, Assignments, and Values Channel Function Value Setting 8-Channel 000 ó 255 0—100% 000 ó 255 Green 0—100% 000 ó 255 Blue 0—100% 000 ó 015 No function Color Macros 016 ó 255 Color macros 000 ó 015 No function Shutter 016 ó... -
Page 14: Configuration (Standalone)
Configuration Set the product in one of the standalone modes to control without a DMX controller. · Connect the product to a suitable power outlet. (Standalone) Never connect a product that is operating in any standalone mode (Static, Automatic, or Sound-Active) to a DMX string connected to a DMX controller. Products in standalone mode may transmit DMX signals that could interfere with the DMX signals from the controller. -
Page 15: Static Colors
Use <UP> or <DOWN> to select the desired dimmer mode. Press <ENTER>. IRC-6 The Wedge™ Tri is fully compatible with the IRC-6 from CHAUVET®. To enable use with the IRC-6, follow the instructions below: (Infrared Remote Press <MENU> repeatedly until SET shows on the display. -
Page 16: Irc-6 (Infrared Remote Control 6)
IRC-6 (Infrared Remote Control 6) Operation Note: Make sure to point the IRC-6 directly at the receiver on the product. Automatic Mode Automatic mode will enable you to run the automatic programs on the product. To turn on Automatic mode: Press <AUTO>... -
Page 17: Master/Slave Mode
Master/Slave The Master/Slave mode allows a single Wedge™ Tri (the “master”) to control the actions of one or more Wedge™ Tri units (the “slaves”) without the need of a DMX controller. Mode The master will be set to operate in either Automatic or Sound-Active mode, while the slaves will be set to operate in Slave mode. -
Page 18: Technical Information
5. T ECHNICAL NFORMATION Product Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life. To maintain optimum performance and Maintenance minimize wear, clean the product at least twice a month. However, usage and environmental conditions contribute to increased cleaning frequency. -
Page 19: Technical Specifications
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 4.3 in (108 mm) 4.3 in (108 mm) 4.1 in (104 mm) 1.4 lb (0.6 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Supply Type Range Voltage Selection Power... -
Page 20: Returns
You must send the merchandise prepaid, in its original box, and with its original packing and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product returned without an RMA number.
