Chauvet Rogue R2 Spot User Manual
Hide thumbs
Also See for Rogue R2 Spot:
- Quick reference manual (40 pages) ,
- Quick reference manual (52 pages)
Table of Contents
Advertisement
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chauvet Rogue R2 Spot
Summary of Contents for Chauvet Rogue R2 Spot
- Page 1 User Manual...
- Page 2 Copyright Notice CHAUVET® owns the content of this User Manual in its entirety, including but not limited to pictures, logos, trademarks, and resources. © Copyright 2014 CHAUVET®. All rights reserved.
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1. Before You Begin ............................1 What Is Included ................................1 Claims ......................................1 Manual Conventions ..................................1 Symbols ....................................... 1 Product At A Glance ..............................2 Safety Notes ................................. 2 Personal Safety .................................... 2 Mounting And Rigging .................................. - Page 4 Table of Contents Offset Mode ................................16 Pan ......................................16 Tilt ......................................16 Gobo ......................................16 Gobo Rotate ....................................16 Gobo 2 ....................................... 16 Color 1 ....................................... 16 Color 2 ....................................... 16 Prism ......................................16 Focus ......................................16 Iris ......................................16 Frost ......................................
-
Page 5: Before You Begin
If the box or the contents (the product and included accessories) appear damaged from shipping or show signs of mishandling, notify the carrier immediately, not CHAUVET®. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. -
Page 6: Product At A Glance
This product contains no user-serviceable parts. Any reference to servicing in this User Manual will only apply to properly trained CHAUVET® certified technicians. Do not open the housing or attempt any repairs. -
Page 7: Introduction
Introduction 2. I NTRODUCTION The Rogue™ R2 Spot is a compact, electronic, moving yoke product equipped with a 240-watt Description LED. It includes 2 color wheels, each with 7 colors plus white and 2 gobo wheels for gobo morphing. It also includes a rotating 3-facet prism, remote focus, frost and iris. ·... -
Page 8: Overview
Introduction Overview Fuse Power Switch DMX In Data In Data Power Out Control Panel Power In Rear View Front View Handle Top View Side View Rogue™ R2 Spot User Manual Rev. 2... -
Page 9: Dimensions
Introduction Dimensions 16.10 in 409 mm 14.09 in 358 mm 10.28 in 261 mm 9.45 in 240 mm 12.87 in 327 mm 13.50 in 343 mm 12.13 in 308 mm 19.25 in 489 mm 4.53 in 115 mm Rogue™ R2 Spot User Manual Rev. 2... -
Page 10: Setup
The listed current rating indicates the maximum current draw during normal operation. For more information, you may download Sizing Circuit Breakers from the CHAUVET® website: www.chauvetlighting.com/download/pro. Always connect this product to a protected circuit with an appropriate electrical ground to avoid the risk of electrocution or fire. -
Page 11: Gobo Wheel
Setup The Rogue™ R2 Spot includes two gobo wheels: 7 rotating gobos plus open on wheel 1 and 8 Gobo Wheel fixed gobos plus open on wheel 2. The diagram shows the gobo number on the wheel, as numbered in the DMX Values tables. -
Page 12: Color Wheel
Setup The Rogue™ R2 Spot includes 2 color wheels with 7 fixed colors plus open (white) in each Color Wheel wheel, as indicated below. The diagram shows the color name on the wheel, as shown in the DMX Values tables. Color Wheel 1 Open (White) -
Page 13: Mounting
2 included omega brackets. Make sure the clamps (such as CLP-15 from CHAUVET®) are capable of supporting the weight of this product. Use two mounting points per product. In addition, use a safety cable to link the product to the structure. -
Page 14: Operation
Operation 4. O PERATION Control Panel Button Function Description <MENU> Exits from the current menu or function <ENTER> Enables the currently displayed menu or sets the currently selected value in to the current function <UP> Navigates upward through the menu list or increases the numeric value when in a function <DOWN>... -
Page 15: Menu Map
Operation Menu Map Main Level Programming Levels Description Address 001–512 Sets the DMX starting address 18CH Selects the DMX mode 21CH Auto Test Runs the product’s test sequence Pan Fine Tilt Tilt Fine P/T Speed Dimmer Dimmer Fine Shutter Color Color2 Run Mode Gobo... -
Page 16: Menu Map (Cont.)
Operation Menu Map (Cont.) Main Level Programming Levels Description Reverse pan operation Pan Reverse Normal pan operation Reverse tilt operation Tilt Reverse Normal tilt operation Rotates control screen view 180° Screen Reverse Normal control screen view Selects the 540° pan angle range Pan Angle Selects the 360°... -
Page 17: Address
Operation This programming level sets the DMX starting address. Address · Starting from the Main Level screen, select Address, press <ENTER>. Set the In this mode, each product will respond to a unique starting address from the DMX controller. All products with the same starting address will respond in unison. This option DMX Address sets the products DMX address. -
Page 18: Setup
Operation This programming level controls the product’s head movement, lamp adjustments, and Setup maintenance timer. · Starting from the Main Level screen, select Setup, press <ENTER>. Reverses the operation of the pan attribute. Pan Reverse 1. Highlight Pan Reverse, press <ENTER>. 2. -
Page 19: Reset Function
Operation Reset Function This programming level allows the user to reset individual functions to the home position. · Starting from the Setup screen level, select Reset Function, press <ENTER>. Pan/Tilt Reset This option resets the Pan/Tilt functions to the home position. 1. -
Page 20: System Information
Operation This programming level shows standard information regarding the product’s operating status. System · Starting from the Main Level screen, select Sys Info, press <ENTER>. Information · Ver: The current software version is displayed on the screen. · Running Mode: The current Running mode is displayed on the screen. ·... -
Page 21: Dmx Values
Operation DMX Values 21CH Channel Function Value Percent/Setting 000ó255 0–100% Fine Pan 000ó255 0–100% Tilt 000ó255 0–100% Fine Tilt 000ó255 0–100% Pan/Tilt Speed 000ó255 0–100% Dimmer 000ó255 0–100% Fine Dimmer 000ó255 0–100% 000ó003 Closed 004ó007 Open 008ó076 Slow to fast Shutter 077ó145 Pulse effect from slow to fast... -
Page 22: Dmx Values (Cont.)
Operation DMX Values (Cont.) 21CH Channel Function Value Percent/Setting (Cont.) 000ó007 Open 008ó015 Gobo 1 016ó023 Gobo 2 024ó031 Gobo 3 032ó039 Gobo 4 040ó047 Gobo 5 Gobo Wheel 1 048ó055 Gobo 6 056ó063 Gobo 7 064ó119 Gobo shake 1–7, slow to fast 120ó127 Open 128ó191... -
Page 23: Dmx Values (Cont.)
Operation DMX Values (Cont.) 21CH Channel Function Value Percent/Setting (Cont.) 000ó007 No function 008ó015 Effect 1 016ó023 Effect 2 024ó031 Effect 3 032ó039 Effect 4 040ó047 Effect 5 048ó055 Effect 6 056ó063 Effect 7 064ó071 Effect 8 072ó079 Effect 9 080ó087 Effect 10 088ó095... -
Page 24: Dmx Values (Cont.)
Operation DMX Values (Cont.) 21CH Channel Function Value Percent/Setting (Cont.) Movement Macro 000ó255 0–100% Speed 000ó007 No function 008ó015 Blackout during pan/tilt (3 sec hold) 016ó023 Blackout while color wheel moving (3 sec hold) 024ó031 Blackout while gobo wheels moving (3 sec hold) 032ó039 Disable pan/tilt blackout (3 sec hold) 040ó047... -
Page 25: Dmx Values (Cont.)
Operation DMX Values (Cont.) 18CH Channel Function Value Percent/Setting (Cont.) 000ó007 Open 008ó015 Yellow 016ó023 Light blue 024ó031 Green 032ó039 Color Wheel 1 040ó047 Magenta 048ó055 Dark blue 056ó063 Orange 064ó127 Split colors 128ó191 Clockwise color scroll, slow to fast 192ó255 Counter-clockwise color scroll, slow to fast 000ó007... -
Page 26: Dmx Values (Cont.)
Operation DMX Values (Cont.) 18CH Channel Function Value Percent/Setting (Cont.) 000ó006 Open 007ó013 Gobo 1 014ó020 Gobo 2 021ó027 Gobo 3 028ó034 Gobo 4 035ó041 Gobo 5 Gobo Wheel 2 042ó048 Gobo 6 049ó055 Gobo 7 056ó063 Gobo 8 064ó120 Gobo shake 1–8, slow to fast 121ó127 Open... -
Page 27: Technical Information
Technical Information 5. T ECHNICAL NFORMATION To maintain optimum performance and minimize wear, you should clean this product Product frequently. Usage and environment are contributing factors in determining the cleaning Maintenance frequency. As a rule, clean this product at least twice a month. Dust build-up reduces light output performance and can cause overheating. -
Page 28: Technical Specifications
Technical Information 6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 16.1 in (409 mm) 13.5 in (343 mm) 19.25 in (489 mm) 46.6 lb (21.2 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection... -
Page 29: Returns
Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return. Clearly label the package with an RMA number. CHAUVET® will refuse any product returned without an RMA number.
