Summary of Contents for Chauvet WELL GOBO
- Page 1 USER MANUAL...
- Page 2 Chauvet reserves the right to revise the content of this document without any obligation to notify any person or company of such revision; however, Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest version from www.chauvetprofessional.com.
-
Page 3: Table Of Contents
Configuration (Standalone) ................Auto Programs ....................... 11 Static Mode ........................11 Dimmer Profiles......................11 LED Frequency ......................11 Back Light ........................11 Control Panel Lock......................11 System Information ......................11 Factory Reset......................... 11 Master/Slave ........................12 WELL Gobo User Manual Rev. 1... - Page 4 Table of Contents Configuration (DMX) ..................Control Personalities ...................... 12 Starting Address......................12 Wireless Settings ......................12 5. Technical Information ..............Product Maintenance ..................6. Technical Specifications ............Photometrics Charts..................Returns.................... Contact Us ..................WELL Gobo User Manual Rev. 1...
-
Page 5: Before You Begin
If the box or the contents (the product and included accessories) appear damaged from shipping, or show signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. -
Page 6: Safety Notes
The minimum ambient temperature is -22°F (-30°C). Do not operate the product at lower temperatures. • In the event of a serious operation problem, stop using this product immediately! If your Chauvet product requires service, contact Chauvet Technical Support. Page 2 of 17 WELL Gobo User Manual Rev. 1... -
Page 7: Introduction
Recharging case can be power-linked to save on power outlets • Recharging case can be charged with the lid closed, saving warehouse space Product Overview Safety loop Display Menu buttons Power button Magnetic base WELL Gobo User Manual Rev. 1 Page 3 of 17... -
Page 8: Product Dimensions
702 mm 12 in 305 mm 6.81 in 18.9 in 173 mm 479 mm 23.36 in 10.11 in 593 mm 257 mm 17.24 in 438 mm 16.7 in 424 mm Page 4 of 17 WELL Gobo User Manual Rev. 1... -
Page 9: Setup
Each WELL Gobo has an auto-ranging battery charger inside the charging case that works with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the power requirements for the WELL Gobo, refer to the label affixed to the product or to the Technical Specifications chart in this manual. -
Page 10: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. For our CHAUVET Professional line of mounting clamps, go to http://trusst.com/products/. Orientation Always mount this product in a safe position, making sure there is adequate room for ventilation, configuration, and maintenance. -
Page 11: Wireless Operation
If the WELL Gobo has already been paired with the W-DMX transmitter, the Signal Strength Indicator in the middle of the LCD screen will show the strength of the signal. In this case, the WELL Gobo is ready to work in Wireless mode. -
Page 12: Dmx Linking
Setup DMX Linking You can link the WELL Gobo to a DMX controller using a wireless DMX connection. If using other DMX- compatible products with this product, each can be controled individually with a single DMX controller. DMX Personalities The WELL Gobo uses a wireless DMX data connection for the 1Ch, 2Ch, 3Ch, and 6Ch DMX personalities. -
Page 13: Operation
Auto 3 Auto 4 Master Master mode (standalone) Master/Slave Slave Slave mode (DMX) Receive Sets the WELL Gobo to receive signal Wireless Setting Reset Resets the wireless setting IR Setting Enables/disables IR receiver Run time Shows the unit’s total run time... -
Page 14: Dmx Values
011 255 Strobe, slow to fast Channel Function Value Percent/Setting Dimmer 000 255 0–100% Dimmer fine 000 255 0–100% Channel Function Value Percent/Setting 000 255 0–100% Page 10 of 17 WELL Gobo User Manual Rev. 1... -
Page 15: Configuration (Standalone)
2. Select PWM Frequency (25Hz, 600Hz, 1200Hz, 2000Hz, 4000Hz, or 6000Hz). Back Light This setting allows for selection of the amount of time the backlight on the WELL Gobo’s display stays on after the last button is pressed on the control panel. -
Page 16: Master/Slave
The Master/Slave mode allows a group of WELL Gobo products (the slaves) to simultaneously duplicate the output of another WELL Gobo (the master) without a DMX controller. To set each of the slaves: 1. Go to the Master/Slave main level. -
Page 17: Technical Information
Softly drag any dirt or grime to the outside of the transparent surface. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. WELL Gobo User Manual Rev. 1 Page 13 of 17... -
Page 18: Technical Specifications
6. Technical Specifications Dimensions and Weight Length Width Height Weight WELL Gobo 10.11 in (257 mm) 6.81 in (173 mm) 12 in (305 mm) 6.6 lb (3 kg) Charging Case 27.64 in (702 mm) 17.24 in (438 mm) 23.36 in (593.4 mm) 71 lb (32.21 kg) -
Page 19: Photometrics Charts
5.98 m 5.98 m 13.00 m 13.00 m 25 m 7.47 m 7.47 m 16.25 m 16.25 m 30 m 8.97 m 8.97 m 19.50 m 19.50 m Field Beam Field WELL Gobo User Manual Rev. 1 Page 15 of 17... -
Page 20: Returns
Returns Returns Send the product prepaid, in the original box, and with the original packing and accessories. Chauvet will not issue call tags. Call Chauvet and request a Return Merchandise Authorization (RMA) number before shipping the product. Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return. -
Page 21: Contact Us
Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, France, Germany, Benelux, or Mexico, contact the dealer of record. WELL Gobo User Manual Rev. 1 Page 17 of 17...
