Owner's Manual
OS900SP Owner's Manual
Unit shown with Seed Box Lid, sold separately
BILLY GOAT SELF PROPELLED OVERSEEDER
OS900SPS, OS900SPH
Owner's Manual
Accessories
Replacement Parts
Seed Box Lid Kit
Chariot Kit
Reel Kit
A convenient way to
Allows the user to ride
Use to replace worn or
enclose the seed box
behind the unit and
damaged reels
decrease fatigue from
walking
P/N 351600
P/N 351601
P/N 351603
Part No 351513
Form No F061311B
1
Advertisement
Related Manuals for Billy Goat OS900SPS
Summary of Contents for Billy Goat OS900SPS
-
Page 1: Replacement Parts
OS900SP Owner’s Manual Unit shown with Seed Box Lid, sold separately BILLY GOAT SELF PROPELLED OVERSEEDER OS900SPS, OS900SPH Owner's Manual Accessories Replacement Parts Seed Box Lid Kit Chariot Kit Reel Kit A convenient way to Allows the user to ride... -
Page 2: Table Of Contents
OS900SP Owner’s Manual CONTENTS SPECIFICATIONS AND SOUND/VIBRATION INSTRUCTION LABELS PACKING CHECKLIST & ASSEMBLY OPERATION MAINTENANCE TROUBLESHOOTING____________________________ PARTS LIST____________ 10-21 Part No 351513 Form No F061311B... -
Page 3: Specifications And Sound/Vibration
OS900SP Owner’s Manual Specifications OS900SPS OS900SPH Engine: HP’ 9.0 HP (6.7kW) 9.0 HP (6.7kW) Engine: Model EX270D50021 GX270K1QA2 Engine: Type Subaru Honda Engine: Fuel Capacity 6.4 qt. (6.1 L) 5.6 qt. (5.3 L) Engine: Oil Capacity 1.06 qt. (1 L) 1.16 qt. -
Page 4: Instruction Labels
INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT Overseeder. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown. -
Page 5: Packing Checklist & Assembly
OS900SP Owner’s Manual PACKING CHECKLIST Your Billy Goat Overseeder is shipped from the factory in one carton, completely assembled. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box the Handle Assembly is attached to the unit and cables could snag. -
Page 6: Operation
OS900SP Owner’s Manual OPERATION FOLDING HANDLE This unit is equipped with a folding upper handle for easier storage and transportation. The handle can be folded by sliding the handle lock loops (item 35) up. This releases the upper handle, allowing it to be folded over the unit. ADJUSTING BLADE DEPTH The depth of the blades can be raised or lowered by rotating the knob located at the rear of the machine. - Page 7 OS900SP Owner’s Manual VERTI-CUTTING OPERATION MOW: Mow the lawn to shorter than the normal cut height (approximately 2" tall) DRY: Be sure grass is dry. Wet conditions can cause increased damage to healthy grass. SET DEPTH: With engine off, set the raking depth so that the blades just touch on a flat surface (i.e.
-
Page 8: Maintenance
OS900SP Owner’s Manual MAINTENANCE ERIODIC AINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Use (daily) Every 25 Hours Inspect for loose, worn or damaged parts. Check engine oil Inspect belts Engine (See Engine Manual) Grease bearings Inspect and clean engine air filter Oil height adjustment linkage SLICING BLADE WEAR... -
Page 9: Troubleshooting
OS900SP Owner’s Manual Troubleshooting P ro b le m P o s s ib le C a u s e S o lu tio n A b n o rm a l v ib ra tio n . · D a m a g e d o r m is s in g b la d e s . L o o s e ·... -
Page 10: Parts List
OS900SP Owner’s Manual SLICING REEL ASSY 351603 PARTS DRAWING ITEM NO DESCRIPTION PART NO. SHAFT VERTICUTTING REEL OS900SP 351111 BLADE VERTICUT OS900SP 351225 SPACER PM REEL OS900SP 351261 SPACER HARDENED REEL OS900SP 351297 SPRING DISC 7/8" ID 351298 NUT 7/8"-14 NC 350341 Part No 351513 Form No F061311B... - Page 11 OS900SP Owner’s Manual ENGINE ASSEMBLY PARTS DRAWING Part No 351513 Form No F061311B...
- Page 12 OS900SP Owner’s Manual ENGINE ASSEMBLY PARTS LIST OS900SPH OS900SPS ITEM NO. DESCRIPTION PART NO. QTY PART NO. QTY ENGINE HONDA 9HP 430287 ‐ ‐ ENGINE SUBARU 9HP ‐ ‐ 351299 ENGINE BASE WA 351100 351100 JACKSHAFT WA 351107 351107 BELT ‐ 6932 POWERATED 351211 351211 BRACKET GUARD BELT UPPER 351203 351203 GUARD BELT UPPER OS900SP 351116 351116 PULLEY IDLER 4" OD X 3/8 BORE 500113 500113 ARM IDLER WA UPPER...
- Page 13 OS900SP Owner’s Manual REEL/REEL DRIVE ASSEMBLY PARTS DRAWING Part No 351513 Form No F061311B...
- Page 14 OS900SP Owner’s Manual REEL/REEL DRIVE ASSEMBLY PARTS LIST OS900SPH OS900SPS ITEM NO. DESCRIPTION PART NO. PART NO. ENGINE BASE WA 351100 351100 HOUSING VERTICUTTER WA OS900SP 351101 351101 FRAME SUPPORT OS900SP WA 351102 351102 BEARING 3/4" CAST FLANGE W/ZERK 350209 350209 PULLEY 0.75" ID X 4" 4L SECTION 351210 351210 BELT 4L 351213 351213 GUARD REEL BELT OS900SP 351117 351117 LABEL DECAL SM CIRCLE 890456 890456 SER HEX WASHER 3/8" ‐ 16 791080 791080 WASHER 1.125 OD X .344 ID X 10 GA...
- Page 15 OS900SP Owner’s Manual HANDLE ASSEMBLY PARTS DRAWING Part No 351513 Form No F061311B...
- Page 16 OS900SP Owner’s Manual HANDLE ASSEMBLY PARTS LIST OS900SPH OS900SPS ITEM NO. DESCRIPTION PART NO. PART NO. FRAME SUPPORT OS900SP WA 351102 351102 PLUG TUBE INSERT 1.25 OD 791056 791056 HANDLE FOLDING OS900SP 351406 351406 BUMPER RECESS 360298 360298 BRACKET CONSOLE OS900SP 351208 351208 GRIP HANDLE 500267 500267 PLUG TUBE INSERT 1" OD 890132 890132 CONTROL MAGURA OS900SP 351209 351209 LOOP FOLDING HANDLE 351231 351231 PIN CLEVIS 3/8 X 2.125...
- Page 17 OS900SP Owner’s Manual SEED BOX ASSEMBLY PARTS DRAWING Part No 351513 Form No F061311B...
- Page 18 OS900SP Owner’s Manual SEED BOX ASSEMBLY PARTS LIST OS900SPH OS900SPS ITEM NO. DESCRIPTION PART NO. PART NO. FRAME SUPPORT OS900SP WA 351102 351102 SEED BOX WA 351103 351103 FRONT WHEEL 14" ASSY 351013 351013 BEARING & FLANGETTE ASSY 850232 850232 AXLE SEED BOX 351223 351223 WHEEL PADDLE SEED WA 351105 351105 PLATE SEED CONTROL OS900SP 351220 351220 BRACKET CONTROL SEED RATE 351222 351222 SPRING EXTENSION .468 X 5.25 440130 440130 SPACER SEED BOX AXLE OS900SP...
- Page 19 OS900SP Owner’s Manual TRANSMISSION ASSEMBLY PARTS DRAWING Part No 351513 Form No F061311B...
- Page 20 OS900SP Owner’s Manual TRANSMISSION ASSEMBLY PARTS LIST OS900SPH OS900SPS ITEM NO. DESCRIPTION PART NO. PART NO. TRANSAXLE 351201 351201 ENGINE BASE WA 351100 351100 FRAME SUPPORT OS900SP WA 351102 351102 JACKSHAFT WA 351107 351107 REAR WHEEL13" X 5" PNEU ASSY 351202 351202 BEARING & FLANGETTE ASSY 850232 850232 BELT 3L540 351215 351215 PULLEY 0.75" ID X 2.75 351214 351214 PULLEY 0.75" ID X 4" 4L SECTION 351210 351210 GUARD DRIVE BELT OS900SP...
- Page 21 OS900SP Owner’s Manual TRANSMISSION ASSEMBLY PARTS LIST OS900SPH OS900SPS ITEM NO. DESCRIPTION PART NO. PART NO. BRACKET TORQUE LIMITING 351294 351294 NUT 5/16"‐18 SER HEX WASHER FLNG ZP 350346 350346 SCREW SPOT WELD 5/16"‐18 X 3/4 W/PROJ 351263 351263 BOLT CARRIAGE 5/16"‐18 X 3/4" ZP 8024039 8024039 SCREWCAP 1/4"‐20 X 1" HCS ZP 8041006 8041006 KEY 3/16" SQ X 1 1/4" 9201080 9201080 CABLE SPEED CONTROL RT 351219 351219 CABLE SPEED CONTROL LFT 351271 351271 SCREWCAP 5/16" SER HEX WSHR FLNG GR. 5 ZP 351264 351264 GROMMET 1.25" HOLE...
