O
PERATING
The following instructions cover lock operations for LC Series locks. The lock models are
battery powered (PowerSaver
instructions.
SUPER MASTER CONTROL
The Super Master Combination is a six-digit combination used to reset the lock to the
factory default combination (50 25 50) in the event the user combination(s) are lost. See
the Super Master Operations sheet (P/N 394.101).
LOCK MODES
A maximum of two users can exist in a lock. A lock can operate in either Single Mode or
Dual Custody Mode.
• Single Mode
Single Mode defaults to having only a Manager User (User 1) in the lock. A second
user (User 2) can then be added by the Manager User (User 1). (See section on
In Single Mode only one valid user combination is required to open the lock - the Manager
User (User 1) combination or the User 2 combination.
Note: Default lock status from the factory is Single Mode with an opening
combination of "50 25 50" for the Manager User (User 1).
•
Dual Custody Mode
Dual Custody Mode defaults to two users in the lock - User 1 and User 2.
Both user combinations are required to open the lock - the User 1 combination and the
User 2 combination.
Note: Manager User Operations are not available in Dual Custody Mode.
LOCK OPERATION & RESPONSES
• Each keystroke generates a green flash
• To cancel entry, press
• The completion of a step within an operation is indicated by a green flash
with a beep
• The successful completion of an operation is indicated by two green flashes
with beeps.
G
• An error is indicated by five green flashes with beeps.
G
G
• A low battery is indicated by 5 series of three green flashes with beeps
G
G
(See Battery Replacement on back page.)
M
I
NSTRUCTIONS
TM
technology). See back page for Battery Replacement
.
.
G
G
G
after a lock opening.
G
LC SERIES
LCLX, LCMX
ODELS
with a beep
.
G
G
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCLX and is the answer not in the manual?

Questions and answers

Related Manuals for Kaba Mas LCLX

Summary of Contents for Kaba Mas LCLX

  • Page 1 LC SERIES LCLX, LCMX ODELS PERATING NSTRUCTIONS The following instructions cover lock operations for LC Series locks. The lock models are battery powered (PowerSaver technology). See back page for Battery Replacement instructions. SUPER MASTER CONTROL The Super Master Combination is a six-digit combination used to reset the lock to the factory default combination (50 25 50) in the event the user combination(s) are lost.
  • Page 2 OPEN/CLOSE THE CONTAINER • For Single Mode (Factory combination is “50 25 50”.) Enter Manager User (User 1) or User 2 combination. • For Dual Custody Mode Enter User 1 or User 2 combination. Enter the second combination. Wrong Try Penalty: 5 wrong tries = 3 min. lockout Each additional wrong try = 3 min.
  • Page 3 Manager User Operations These operations are only available in Single Mode and can only be performed by the Manager User (User 1). All Manager User Operations involve management of User 2. User 2 can have a lock access status of “Enabled” or “Disabled”. If “Enabled”, User 2 can open the lock.
  • Page 4 Battery Replacement Read all instructions before attempting to replace the battery in an LC Series lock. To replace the battery, you must first remove the keypad Figure 1 assembly. To do so, insert the blade of a flat head screwdriver under the keypad housing at a point about 15 degrees to the right of 6 o’clock on the face of...
