Assembly and Operating Instructions for
Outback® Trekker Portable Gas BBQ
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
RG47F
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG47F and is the answer not in the manual?

Questions and answers

Related Manuals for Outback RG47F

Summary of Contents for Outback RG47F

  • Page 1 Assembly and Operating Instructions for Outback® Trekker Portable Gas BBQ RG47F Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® CODE PART Trekker Portable Gas BBQ Hood HOOD Hood Handle Hood Hinge...

  • Page 3: Parts Diagram

    Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice.
  • Page 5 Assembly IMPORTANT! Remove any internal components or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in • case sharp edges are present. Please read the Important Information section carefully before assembly and use of your •...
  • Page 6 Insert the Grease Cup (B10) by sliding it underneath the Barbecue Body (B1). Attach the hood assembly onto the barbecue body by aligning the Hood Hinge (A3) with the Body Hinge (B11), and secure with a Hinge Pin (D2) and R Shape Clip (D3).
  • Page 7 Multiple Use Option One Place the Cooking grill (B7) and Flame Tamer (B6) into the barbecue body by aligning the three locating grooves with the three supporting blocks, ensuring it lies level within the body. NOTE: Please align the “Arrow” mark on the griddle or flame tamer with the supporting block on the right for easy assembly.
  • Page 8 Grill Lifting Handle Usage Reference To remove and replace Cooking Griddle To remove and replace cooking vessel support To remove and replace cooking grill To remove and replace flame tamer...

  • Page 9: Leak Testing

    Leak Test Diagram 1. Maximum diameter or breadth is 315mm. 2. Maximum height (regulator included) is 580mm. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE.

  • Page 10: Gas, Regulator And Hose

    Important Information Before you use your barbecue, perform a leak test. This is the only safe and sure way Please read these instructions carefully to detect any gas leaking from joints and connections of the barbecue after assembly. before assembly and use of your barbecue. Leak test annually, and whenever the gas Retain these...

  • Page 11: Installation

    INCORRECT OR FAULTY REGULATOR IS with the cooking area as a solid plate — this DANGEROUS AND WILL INVALIDATE ANY includes baking dishes. Full coverage will WARRANTY. Please consult your local gas cause excessive build-up of heat and dealer for the most suitable gas bottles and damage the barbecue.

  • Page 12: Care And Maintenance

    • After ignition, turn the burner to the low after each cooking session. If the barbecue is to be used for large gatherings, it will be position for 3-5 minutes in order to pre-heat the barbecue. This should be done before necessary to turn off and cool the barbecue each cooking session.
  • Page 13 Flame Tamer outside for any length of time, especially during Remove any food residue from the flame tamer the winter months. Heavy-duty OUTBACK® surface with a plastic or wooden scraper or barbecue covers and other accessories are brass wire brush. Do not use a steel scraper or available from your local stockist.

  • Page 14: Technical Specifications

    Heat Injector Burners Gas /Pressure sources of heat or ignition. Do not let children Approval Input Size tamper with the bottle. Outback® Trekker 0359 Butane: 28-30mbar 0.94mm Portable 359BR665 Propane: 37mbar When using the barbecue after extended Gas BBQ...

  • Page 15: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode or ignition button wire is loose Reconnect wire...
  • Page 16 OUTBACK® WARRANTY OUTBACK® barbecues are warranted to the original purchaser against defects in materials and workmanship. OUTBACK® will supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
