Cable Adjustment - TuffStuff Multi-Press SP-403 Assembly Manual

It is imperative that you maintain proper cable adjustment to ensure
a safe and smooth operation.
2
FIG. 25 Affix the Weight Shroud (#2)
Stack Frame (#1) and at the top of the
ing four Hex Head Cap Screws 1/4-20 X 3/4 (#21), and four Flat
Washers 1/4" (#20).
SP-403 Multi-Press

CABLE ADJUSTMENT

5
to the bottom of the Weight
Guide Rod Retainer (#5)
Caution: The Cable should be inspected and adjusted peri-
odically to avoid any slack in the cable which would, conse-
quently, prevent any damage to the equipment or personal in-
jury.
87
88
69
9
Cable Adjustment
1. Loosen the Finished Hex Nut 1/2-13 (#69).
2. Thread the Cable Hex Tap Bolt 1/2-13 X 3 (#88) in or out
of the threaded socket of the
to give the
3. Re-tighten the Finished Hex Nut 1/2-13 (#69) to complete
the adjustment.
2
FIG. 26 Insert the two Plastic Shroud Edge Protectors (#12) to both
us- Shrouds (#2, #3), in the position as shown above, and slide them all
the way down.
66
Top Plate Selector Bar (#9)
Cable (#87) proper tension.
Caution: Make sure the Cable Hex Tap Bolt 1/2-13
X 3 (#88) is threaded at least 1/2" into the threaded
socket of the Top Plate Selector Bar (#9)
cable adjustment has been completed.
12
3
12
once the
8
