Installation Instructions
Model Numbers:
MCVST42N, MCVST42NE, MCVST42LP, MCVST42LPE
ANSI Z21.50-2014 • CSA 2.22-2014
ZERO CLEARANCE VENTED GAS FIREPLACE
Model Numbers:
MCVST42NH, MCVST42NHE, MCVST42LPH, MCVST42LPHE
ANSI Z21.88-2014 • CSA 2.33-2014
ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
Certified to:
Certified to:
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For Propane Horizontal installations the
venting must be an additional one foot
above the minimum vertical rise off the flue
This appliance may be installed in an
aftermarket, permanently located,
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
before going horizontal.
A Division of R-Co. Inc.
2340 Logan Ave.
Winnipeg, Manitoba Canada
R2R 2V3 Ph.: (204) 632-1962
Printed in Canada May 5, 2015
Part# 42MCVST-MAN14
