Vertical Slope Top, Model J

UNT-SVX07B-EN
Vertical Slope Top Unit Dimensions (in.) and Weights (lb)
Unit Size 02–03
A 33-5/16" 38-5/16"
B 21-5/16" 26-5/16"
C 7-5/8" 7-1/8"
D 18"
E 19-5/16" 24-5/16"
F 41-5/16" 46-5/16"
Operating
97 125
Weight
Shipping
84 112
Weight
Notes:
1. Coil connections are always on the drain pan side and opposite the control
box and unit control.
2. Coil connections are 5/8" O.D. sweat. See
3. All duct collar dimensions are to the outside of the collar.
4. See p. 34 for dimensions for outside air openings.
5. Serviceability for some components within this unit may require panel or
drain pan removal.
Dimensions and Weights
04 06 08
47-13/16" 56-5/16"
35-13/16" 44-5/16"
8-7/8" 7-1/8"
24" 30" 42"
33-13/16" 42-5/16"
55-13/16" 64-5/16"
155 164
139 148
p. 30 and p. 31 for locations.
10–12
75-5/16"
63-5/16"
7-5/8"
60"
61-5/16"
83-5/16"
218
200
25
