Installation and Operation Manual
Side Discharge AC Models
For coastal applications where units are installed within one (1) mile of salt water, epoxy coated models are recommended. These models
have an 8 week lead time after order.
4TTL5024N1000A
4TTL5030N1000A
4TTL5036N1000A
4TTL5042N1000A
4TTL5048N1000A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
June 2022
E E p p o o x x y y C C o o a a t t e e d d M M o o d d e e l l
4TTL5024N1COTA
4TTL5030N1COTA
4TTL5036N1COTA
4TTL5042N1COTA
4TTL5048N1COTA
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
1 1 8 8 - - A A C C 1 1 2 2 6 6 D D 1 1 - - 1 1 A A - - E E N N
N N o o t t e e : : "Graphics in this document are for representation
only. Actual model may differ in appearance."

Advertisement

Table of Contents
loading

Related Manuals for Trane 4TTL5024N1000A

Summary of Contents for Trane 4TTL5024N1000A

  • Page 1 8 week lead time after order. E E p p o o x x y y C C o o a a t t e e d d M M o o d d e e l l 4TTL5024N1000A 4TTL5024N1COTA...
  • Page 2 . . 18-AC126D1-1A-EN ©2022 Trane...

  • Page 3: Table Of Contents

    Table of Contents Unit Location Considerations ....4 System Start Up ......19 Unit Location Considerations .

  • Page 4: Unit Location Considerations

    Unit Location Considerations Table 1. Unit Dimensions (in inches) and Weight H x D x W (in) Weight * (lb) Models 4TTL5024N1 36.75 x 17 1/2 x 47 32.75 47.0 36.75 17.5 19.5 20.5 36.75 x 17 1/2 x 47 4TTL5030N1 32.75 47.0...
  • Page 5 U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Table 2.

  • Page 6: Unit Location Considerations

    U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Unit Location Considerations Table 3.
  • Page 7 U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Table 3.

  • Page 8: Unit Preparation

    U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Unit Preparation Check for damage and report promptly to the carrier any damage found to the unit.

  • Page 9: Refrigerant Line Considerations

    U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Refrigerant Line Considerations Table 7.
  • Page 10 U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Table 11.
  • Page 11 U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Table 14.

  • Page 12: Refrigerant Line Brazing

    U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Refrigerant Line Brazing Table 16.
  • Page 13 U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Table 16.

  • Page 14: Refrigerant Line Leak Check

    U U n n i i t t L L o o c c a a t t i i o o n n C C o o n n s s i i d d e e r r a a t t i i o o n n s s Refrigerant Line Leak Check Table 17.

  • Page 15: Service Valves

    Service Valves Table 18. Open the Gas Service Valve 1/4 Turn Only Important: Leak check and evacuation must be completed before opening the service valves. Counterclockwise Note: Do not vent refrigerant gases into the atmosphere. for Full Open Position Remove valve stem cap. Using a wrench, turn valve stem 1/4 turn counterclockwise to the fully open position.

  • Page 16: Communicating

    Electrical — Low Voltage Non Communicating Table 20. Low Voltage Maximum Wire Length 24 VOLTS The table defines the maximum total length of low voltage wiring WIRE SIZE MAX. WIRE LENGTH from the outdoor unit, to the indoor unit, and to the thermostat. Note: The use of color coded low voltage wire is recommended to 18 AWG 150 Ft...
  • Page 17 E E l l e e c c t t r r i i c c a a l l — — L L o o w w V V o o l l t t a a g g e e N N o o n n C C o o m m m m u u n n i i c c a a t t i i n n g g 2 Stage AC Thermostat AUX 1 AUX 1...

  • Page 18: Electrical - High Voltage

    E E l l e e c c t t r r i i c c a a l l — — L L o o w w V V o o l l t t a a g g e e N N o o n n C C o o m m m m u u n n i i c c a a t t i i n n g g Electrical —...

  • Page 19: System Start Up

    E E l l e e c c t t r r i i c c a a l l — — L L o o w w V V o o l l t t a a g g e e N N o o n n C C o o m m m m u u n n i i c c a a t t i i n n g g System Start Up Set the system thermostat to OFF.

  • Page 20: Subcooling Charging In Cooling Between 55° F And 120° Od

    Subcooling Charging in Cooling between 55° F and 120° OD Ambient Trane has always recommended installing Trane 4. Measure Liquid Line Temperature and Refrigerant approved matched indoor and outdoor systems. Pressure at service valves. 5. Determine total refrigerant line length, and height The benefits of installing approved indoor and outdoor (lift) if indoor section is above the condenser.

  • Page 21: System Charge Adjustment

    System Charge Adjustment Table 24. Temperature Measurements (Systems can be rated with TXV, EEV or Piston. Ensure charging method is correct). Check the outdoor temperatures. 120° F Subcooling using “Charging Mode-Cooling” is the only recommended method of charging between 55 ° F and 120° F ambient outdoor temperature.

  • Page 22: Refrigerant Charging Chart

    Refrigerant Charging Chart R-410A REFRIGERANT CHARGING CHART DESIGN SUBCOOLING (°F) LIQUID TEMP (°F) LIQUID GAGE PRESSURE (PSI) 18-AC126D1-1A-EN...

  • Page 23: Subcool Charging Charts

    Subcool Charging Charts Figure 1. 2.0 and 2.5 Ton Models Figure 3. 3.5 and 4.0 Ton Models SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) Add 4° 1° 1°...

  • Page 24: Charging The Unit

    Charging the Unit Table 26. Stabilize the system Wait 20 minutes for the system condition to stabilize between adjustments. Note: When the Liquid Line Temperature and Gage Pressure 20 MIN. approximately match the chart, the system is properly charged. Remove gauges. Replace service port caps to prevent leaks.
  • Page 25 C C h h a a r r g g i i n n g g t t h h e e U U n n i i t t Table 29. Proper Gage Pressure Adjust refrigerant level to attain proper gage pressure. Add refrigerant if the Liquid Gage Pressure is lower than the chart value.

  • Page 26: Checkout Procedures

    Checkout Procedures The final phase of the installation is the system Checkout Procedures. The following list represents the most common items covered in a Checkout Procedure. Confirm all requirements in this document have been met. ☐ All wiring connections are tight and properly secured. ☐...

  • Page 27: Wiring Diagrams

    Wiring Diagrams Figure 4. 2.0, 2.5 and 3.0 Ton Models 18-AC126D1-1A-EN...
  • Page 28 W W i i r r i i n n g g D D i i a a g g r r a a m m s s Figure 5. 2.0, 2.5 and 3.0 Ton Models 18-AC126D1-1A-EN...
  • Page 29 W W i i r r i i n n g g D D i i a a g g r r a a m m s s Figure 6. 3.5 and 4.0 Ton Models 18-AC126D1-1A-EN...
  • Page 30 W W i i r r i i n n g g D D i i a a g g r r a a m m s s Figure 7. 3.5 and 4.0 Ton Models 18-AC126D1-1A-EN...

  • Page 31: Pressure Curves

    Pressure Curves Figure 8. 2.0 and 2.5 Ton Models PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM OUTDOOR TEMPERATURE (Degree F) 4TTL5024N1 4TTL5030N1 INDOOR ENTERING WET BULB CURVES...
  • Page 32 P P r r e e s s s s u u r r e e C C u u r r v v e e s s Figure 9. 3.0 Ton Models PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM...
  • Page 33 P P r r e e s s s s u u r r e e C C u u r r v v e e s s Figure 10. 3.5 and 4.0 Ton Models PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM...
  • Page 34 N N o o t t e e s s 18-AC126D1-1A-EN...
  • Page 35 N N o o t t e e s s 18-AC126D1-1A-EN...
  • Page 36 The AHRI Certified mark indicates Trane U.S. Inc. participation in the AHRI Certification program. For verification of individual certified products, go to ahridirectory. org. Trane has a policy of continuous data improvement and it reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
