Operating Mode (Model WDS)
This section describes how to operate the Trane wireless sensor, model WDS.
example of a model WDS that has been configured and is in operating mode.
Figure 20. Wireless sensor (model WDS) in operating mode
System settings (not available for fan-coil or Force-Flo units)
Changing Room Temperature
This symbol shows the current room
temperature, or your setpoint selection
.
while you are making an adjustment.
When you select a setpoint, this symbol
appears.
Changing Heating and Cooling Room Temperature Settings (applies to some systems)
Some systems allow you to select both heating and
cooling room temperature settings. If your system
has this option, this symbol appears when you adjust
the temperature setting.
When you adjust the cooling setting, the top arrow
and snowflake flash.
When you adjust the heating setting, the bottom
arrow and flame flash.
UNT-SVX07B-EN
The minimum change in temperature setpoint required to force a sensor transmission is:
– 0.1°C for a model WDS sensor
Test symbols (appear only when Test button is pushed
Occupancy indicator/Error code
Temperature
Fan settings
Keypad
Test button
1. To increase the room temperature, press
To decrease the room temperature, press
2. To confirm, press
to the home screen.
1. Press or
2. If in cooling mode, press
heating mode, press
3. Press or
4. To confirm, press
appear.
Controls Interface
Figure 20
.
or wait 5 seconds. The display will return
to select the heating/cooling setting.
to change to heating mode. If in
to change to cooling mode.
to select the heating/cooling setting.
or wait 5 seconds. The home screen will
shows an
.
.
