Contura C 550A Installation Instruction page 10

GB
ASSEMBLY
58
4
!
Clean the glass thoroughly before
installing the side panels!
Remove the protective plastic
!
from along the bent edge
before installing the sides. After
installing the stove, remove the
protective plastic. It is important
to remove all the protective
plastic.
Ensure that your hands are clean
to avoid leaving marks on the
aluminium sides.
Hold the side panel approximately 20 mm above the base panel and
turn the side panel's front edge around the edge of the base frame.
Hook the side panel on the back panel. Align and depress the side
panel end over the base panel's shaft pin.
